GBP 57 EG-UNC 90º Full UNC UNC-LH EG-UNC LH Solid h6 profile 60° carbide DIN 4 6 6535 HA ≤2×D ≤2×D GARANT Master TM solid carbide plain shank thread mill with countersink Solid carbide thread milling cutters with irregular cutting edge spacing and an increased number of cutting edges. Due to the irregular cutting edge spacing they achieve very smooth running and long tool life. Newly developed universal geometry and high-performance coating for use across a wide spectrum of materials. ■ Significantly reduced vibration due to irregular cutting edge spacing. 13 9733 ■ Increased number of cutting edges. ■ The latest generation of AlTiN-based HiPIMS coating. Countersink ■ Corrected thread profile for avoidance of profile distortions. Advantage: Incorporating a countersink profile for a 90° countersink and thread milling in a single operation. L Application: For UNC unified coarse threads ASME-B1.1. L1 Note: HB and HE shanks are available at the same price as HA LC LS Order HB shank: with No. 139733 + 129100 HB Order HE shank: with No. 139733 + 129100 HE ⌀ DC ⌀ DS ⌀ D1 Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H M M S K N ​ ​ ​ ​ ​ ​ 13 9733 220 220 180 140 130 120 90 80 45 85 50 82 75 50 120 200 ● ● ● ● UNC 13 9733 Threads ⌀ DC Lc Ls L ⌀ Ds ⌀ D1 Programming No. of 11D per inch value for teeth GARANT Master TM countersink L1 Z < 750 N plain shank thread mill with countersink fz 2×D AlTiN ​ mm mm mm mm mm mm mm ​ mm 10-24 eShop 24 3.55 10.02 36 58 6 5.75 10.91 4 0.03 1/4-20 eShop 20 4.7 13.29 40.6 68 8 7 14.36 4 0.05 5/16-18 eShop 18 6.1 16.18 43.3 75 10 9 17.35 4 0.06 3/8-16 eShop 16 7.5 19.8 45 82 12 11 21.06 4 0.07 7/16-14 eShop 14 8.8 22.61 53.6 92 12 11.75 24.02 6 0.08 1/2-13 eShop 13 10.3 26.32 50.6 94 14 13.5 27.77 6 0.09 9/16-12 eShop 12 11.6 30.63 56.8 106 16 15 32.22 6 0.1 5/8-11 eShop 11 13 33.41 54 108 18 17 35.1 6 0.11 3/4-10 eShop 10 15.9 39.29 61.1 120 20 19.75 41.12 6 0.13 EG-UNF Full UNF UNF-LH EG-UNF LH Solid h6 profile 60° carbide DIN 4 6 6535 HA ≤2×D ≤2×D 13 GARANT Master TM solid carbide plain shank thread mill Solid carbide thread milling cutters with irregular cutting edge spacing and an increased number of cutting edges. Due to the irregular cutting edge spacing they achieve very smooth running and long tool life. Newly developed universal geometry and high-performance coating for use across a wide spectrum of materials. ■ Significantly reduced vibration due to irregular cutting edge spacing. ■ Increased number of cutting edges. ■ The latest generation of AlTiN-based HiPIMS coating. ■ Corrected thread profile for avoidance of profile distortions. 13 9737 Application: For UNF unified fine threads ASME-B1.1. L Note: HB and HE shanks are available at the same price as HA LC LS Order HB shank: with No. 139737 + 129100 HB Order HE shank: with No. 139737 + 129100 HE ⌀ DC ⌀ DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H M M S K N ​ ​ ​ ​ ​ ​ 13 9737 220 220 180 140 130 120 90 80 45 85 50 82 75 50 120 200 ● ● ● ● UNF 13 9737 Threads per ⌀ DC Lc Ls L ⌀ Ds No. of teeth 11D inch Z GARANT Master TM < 750 N plain shank thread mill fz 2×D AlTiN ​ mm mm mm mm mm ​ mm 10-32 eShop 32 3.81 9.9 36.8 58 6 4 0.04 1/4-28 eShop 28 5.1 13.12 40.8 64 6 4 0.05 5/16-24 eShop 24 5.95 16.36 38.1 64 6 4 0.07 3/8-24 eShop 24 7.95 19.54 37.7 68 8 4 0.08 7/16-20 eShop 20 7.95 23.44 36 70 8 6 0.09 1/2-20 eShop 20 9.95 25.98 44 82 10 6 0.1 9/16-18 eShop 18 11.95 28.87 50 92 12 6 0.1 5/8-18 eShop 18 11.95 33.09 45.7 92 12 6 0.11 3/4-16 eShop 16 13.95 38.83 49 102 14 6 0.13 7/8-14 eShop 14 15.95 46.17 48.7 110 16 6 0.14 1-12 eShop 12 19.95 51.77 51.5 120 20 6 0.15 350
