GBP 57 EG-UNF 90º Full UNF UNF-LH EG-UNF LH Solid h6 profile 60° carbide DIN 4 6 6535 HA ≤2×D ≤2×D GARANT Master TM solid carbide plain shank thread mill with countersink Solid carbide thread milling cutters with irregular cutting edge spacing and an increased number of cutting edges. Due to the irregular cutting edge spacing they achieve very smooth running and long tool life. Newly developed universal geometry and high-performance coating for use across a wide spectrum of 13 9738 materials. Countersink ■ Significantly reduced vibration due to irregular cutting edge spacing. ■ Corrected thread profile for avoidance of profile distortions. ■ Increased number of cutting edges. ■ The latest generation of AlTiN-based HiPIMS coating. Advantage: Incorporating a countersink profile for a 90° countersink and thread milling in a single L operation. L1 Application: For UNF unified fine threads ASME-B1.1. LC LS Note: HB and HE shanks are available at the same price as HA Order HB shank: with No. 139738 + 129100 HB ⌀ DC ⌀ DS Order HE shank: with No. 139738 + 129100 HE ⌀ D1 Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H M M S K N ​ ​ ​ ​ ​ ​ 13 9738 220 220 180 140 130 120 90 80 45 85 50 82 75 50 120 200 ● ● ● ● UNF 13 9738 Threads ⌀ DC Lc Ls L ⌀ Ds ⌀ D1 Programming val- No. of 11D per inch ue for countersink teeth Z L1 < 750 N GARANT Master TM plain shank thread mill with countersink fz 2×D AlTiN ​ mm mm mm mm mm mm mm ​ mm 10-32 eShop 32 3.81 9.1 36.8 58 6 5.75 9.86 4 0.04 1/4-28 eShop 28 5.1 13.12 41.4 68 8 7 14 4 0.05 5/16-24 eShop 24 6.5 16.36 43.7 75 10 9 17.33 4 0.07 3/8-24 eShop 24 8 19.54 46.3 82 12 11 20.55 4 0.08 7/16-20 eShop 20 9.3 23.45 53.4 92 12 11.75 24.61 6 0.09 1/2-20 eShop 20 10.9 25.99 51.8 94 14 13.5 27.14 6 0.1 9/16-18 eShop 18 12.3 27.88 59.4 106 16 15 29.12 6 0.1 5/8-18 eShop 18 13.9 33.11 56.3 108 18 17 34.35 6 0.11 3/4-16 eShop 16 16.8 38.85 62.7 120 20 19.75 40.23 6 0.13 NPT Solid 60° carbide ANSI B1.20.1 1:16 h6 DIN 6535 HA Full profile 4 6 13 GARANT Master TM solid carbide plain shank thread mill Solid carbide thread milling cutters with irregular cutting edge spacing and an increased number of cutting edges. Due to the irregular cutting edge spacing they achieve very smooth running and long tool life. Newly developed universal geometry and high-performance coating for use across a wide spectrum of materials. ■ Significantly reduced vibration due to irregular cutting edge spacing. ■ Increased number of cutting edges. ■ The latest generation of AlTiN-based HiPIMS coating. 13 9739 ■ Corrected thread profile for avoidance of profile distortions. Application: Tapered pipe threads (NPT) to ANSI B1.20.1, for threads with sealants. L Note: HB and HE shanks are available at the same price as HA. LC LS Order HB shank: with No. 139739 + 129100 HB. Order HE shank: with No. 139739 + 129100 HE. ⌀ DC ⌀ DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H M M S K N ​ ​ ​ ​ ​ ​ 13 9739 220 220 180 140 130 120 90 80 45 85 50 82 75 50 120 200 ● ● ● ● NPT 13 9739 Threads per ⌀ DC Lc Ls L ⌀ Ds No. of teeth Z 11D inch < 750 N GARANT Master TM plain shank thread mill fz AlTiN ​ mm mm mm mm mm ​ mm 1/16-27 eShop 27 5.39 8.93 39.3 58 6 4 0.08 1/8-27 eShop 27 7.39 8.93 48.1 68 8 6 0.09 1/4-18 eShop 18 9.11 13.39 49 75 10 6 0.1 3/8-18 eShop 18 11.11 13.38 55 82 12 6 0.11 1/2-14 eShop 14 12.88 17.2 61.9 94 14 6 0.13 351
