GBP 57 Threads that can be produced with the single profile thread mill 139620 and 139625 Article number ISO coarse thread ISO fine thread UNF UNEF UN-16 UN-20 UNS 139620 M1 M1X0.25; M1.1X0.25; M1X0.2; M1.1X0.2; 139625 M1 M1.2X0.25 M1.2X0.2 139620 M1.4 M1.4X0.3 M1.4X0.2; M1.4X0.25 139625 M1.4 139620 M1.6 M1.6X0.35; M1.7X0.35; M1.6X0.2; M1.6X0.25; 139625 M1.6 M1.8X0.35 M1.8X0.2; M1.8X0.25 M2X0.2; M2X0.25; 139620 M2 M2X0.4; M2.3X0.4 M2X0.35; M2.2X0.2; No. 2-64 139625 M2 M2.2X0.25; M2.2X0.35 139620 M2.5 M2.5X0.2; M2.5X0.25; M2.5X0.45; M2.6X0.45 139625 M2.5 M2.5X0.35 139620 M3 M3X0.2; M3X0.25; M3X0.5 No. 10-56; No. 12-56 139625 M3 M3X0.35 139620 M3.5 M3.5X0.6 M3.5X0.35; M3.5X0.5 No. 10-48; No. 12-48 139625 M3.5 139620 M4 M4X0.35; M4.5X0.35; M4X0.7 No. 10-40; No. 12-40 139625 M4 M4X0.5; M4.5X0.5 139620 M5 M5X0.8 M5X0.35; M5X0.5 No. 12-32 No. 12-36; 1/4 inch-56 139625 M5 1/4"-27; 1/4"-36; 1/4"-40; M6X0.5; M6X0.75; 139620 M6 1/4"-48; 5/16"-27; M6X1; M7X1 M6.5X0.75; M7X0.5; 1/4"-28 1/4"-32; 5/16"-32 139625 M6 5/16"-36; 5/16"-40; M8X0.5 5/16"-48; 3/8"-36; 3/8-40 3/8"-27; 7/16"-24; 139625 M8 M8X1.25; M9X1.25 M8X1; M9X1 3/8"-24 3/8"-32 7/16"-27 M10X0.75; M10X1; 7/16"-18; 1/2"-18; 139625 M10 M10X1.5; M11X1.5 M10X1.25; M11X0.75; 7/16"-20; 1/2"-20 7/16"-28; 1/2"-28 1/2"-24; 1/2"-27; 5/8"-27 M11X1; M11X1.25 9/16"-27; 3/4"-24; M12X1; M12X1.25; 9/16"-24; 5/8"-24; 139625 M12 M12X1.75 9/16"-18; 5/8"-18 1/2"-16; 9/16"-16 9/16"-20 3/4"-27; 7/8"-24; 7/8"-27; M12X1.5; M13X1; M14X1 11/16"-24 1"-24; 1"-27 M14X1.25; M14X1.5; 3/4"-20; 13/16"-20; 5/8"-16; 11/16"-16; 9/16"-14; 5/8"-14; M14X1.75; M15X1; 139625 M14 M14X2; M16X2 3/4"-16; 7/8"-14 7/8"-20; 15/16"-20; 13/16"-16; 7/8"-16; 5/8"-20; 11/16"-20 3/4"-14; 3/4"-18; 7/8"-18; M16X1.5; M18X1.5; 1"-20 15/16"-16; 1"-16 1"-14; 1"-18 M18X2; M20X1.5; M20X2 Partial M M-LH UN UN-LH Solid DIN h6 profile 60° carbide 13 DIN 4 6 6535 HA ≤2×D ≤2×D GARANT Master TM solid carbide single profile thread mill Solid carbide thread milling cutters with irregular cutting edge spacing and an increased number of cutting edges. Due to the irregular cutting edge spacing they achieve very smooth cutting action and long tool life. Newly developed universal geometry and high-performance coating for use across a wide spectrum of materials. ■ Significantly reduced vibration due to irregular cutting edge spacing. ■ Increased number of cutting edges. 13 9620_M3 13 ■ Latest-generation AlTiN-based HIPIMS coating. ■ Corrected thread profile for avoidance of profile distortions. Size M1–M3,5 – Parallel coolant channels. Size M4–M6 – Axial cooling grooves on the shank. 13 9620_M6 Advantage: Significantly less radial pressure than with multi-tooth thread mills. The tool can also be used for additional thread profiles (UN; UN-LH) for various pitches and diameters. See overview for possible threads. Note: HB and HE shanks are available at the same price as HA. L HB shank: order with No. 139620 + 129100 HB. L1 LS HE shank: order with No. 139620 + 129100 HE. ⌀ DC ⌀ DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H M M S N N N N ​ ​ ​ ​ ​ ​ 13 9620 220 220 180 140 130 120 90 80 45 35 82 75 50 200 100 100 150 ● ● ● ● M 13 9620 Thread pitch ⌀ DC Lc Ls L1 L ⌀ Ds No. of 11D CRP range teeth GARANT Master TM Z < 1400 N solid carbide single profile thread mill fz fz 2×D AlTiN mm mm mm mm mm mm mm ​ mm mm M1 eShop 0.1 – 0.25 0.69 0.33 42 2 58 6 4 0.005 0.003 M1,4 eShop 0.14 – 0.3 1.03 0.39 42 3 58 6 4 0.008 0.004 M1,6 eShop 0.14 – 0.35 1.17 0.46 42 3.8 58 6 4 0.008 0.005 M2 eShop 0.15 – 0.4 1.51 0.53 42 4.2 58 6 4 0.008 0.007 M2,5 eShop 0.17 – 0.45 1.94 0.59 42 5.2 58 6 4 0.008 0.01 M3 eShop 0.18 – 0.5 2.38 0.66 42 6.3 58 6 4 0.01 0.02 M3,5 eShop 0.22 – 0.6 2.71 0.79 42 7.3 58 6 4 0.01 0.025 M4 eShop 0.26 – 0.7 3.1 0.93 46 8.4 58 6 6 0.02 0.03 M5 eShop 0.35 – 0.8 3.9 1.06 44.5 10.4 58 6 6 0.03 0.04 M6 eShop 0.5 – 1 4.7 1.33 42.9 12.5 58 6 6 0.04 0.05 341
