GBP 57 M C 60° HSS-E- DIN DIN h9 PM 2174 13 3 ≤1.5×D ≤1.5×D ​Fluteless machine tap without oil grooves DIN 2174 (≈ DIN 371 ≤ M10; ≈ DIN 376 ≥ M12). ISO 2X 13 9135/9143 – Tolerance class: ISO 3X / 6GX = Oversize 0.02 − 0.04 mm. 6HX 13 9115/9125/9135 – The innovative polygon form permits a wide application spectrum. 13 9115 The multi-function layer structure achieves maximum service life even ​ in high-tensile materials. 13 9125/9130 – Size M1–M1.4 – tolerance class: ISO 1X / 4HX. Size M1,7; M2,3; M2,6 – with old DIN profile. ISO 2X 13 9130/9143 – HOLEX Pro Form: High-performance fluteless tap for use in a wide range 6HX of materials. 13 9125 ≥M1.6 ​ ■ HSS-E-PM tool material for high wear resistance. ■ The latest-generation optimised HIPIMS TiN coating. Application: 13 9135/9143 – For components which are galvanised after threading or which shrink ISO 2X slightly when hardened. 6HX ≥M1.6 ​ 13 9130 ISO 3X 6GX ​ 13 9135 ISO 3X 6GX ​ 13 9143 L ØD Ø DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S N ​ ​ ​ ​ ​ ​ 13 13 9115 13 9125/​9135 42 42 32 37 27 32 22 27 17 22 17 12 12 7 22 22 ● ● ● ● ● 13 9130/​9143 20 20 27 25 25 10 8 20 ● ● ● M 13 9115 13 9125 13 9130 13 9135 13 9143 Thread pitch L ⌀ Ds □ Tapping hole ⌀ 11H 11H 11H 12I 12I guide value HOLEX Pro Form HOLEX Pro Form Fluteless machine tap Fluteless machine tap fluteless machine tap fluteless machine tap without oil grooves without oil grooves without oil grooves without oil grooves 6HX 6HX 6HX 6GX 6GX TiN TiN TiN TiN TiN mm mm mm mm mm M1 – eShop eShop – – 0.25 40 2.5 2.1 0.9 M1,2 – eShop eShop – – 0.25 40 2.5 2.1 1.1 M1,4 – eShop eShop – – 0.3 40 2.5 2.1 1.25 M1,6 – eShop eShop – – 0.35 40 2.5 2.1 1.45 M1,7 – eShop eShop – – 0.35 40 2.5 2.1 1.55 M2 eShop eShop eShop eShop eShop 0.4 45 2.8 2.1 1.85 M2,3 – eShop eShop – – 0.4 45 2.8 2.1 2.1 M2,5 eShop eShop eShop – – 0.45 50 2.8 2.1 2.3 M2,6 – eShop eShop – – 0.45 50 2.8 2.1 2.4 M3 eShop eShop eShop eShop eShop 0.5 56 3.5 2.7 2.8 M3,5 eShop eShop eShop – – 0.6 56 4 3 3.25 M4 eShop eShop eShop eShop eShop 0.7 63 4.5 3.4 3.7 M5 eShop eShop eShop eShop eShop 0.8 70 6 4.9 4.65 M6 eShop eShop eShop eShop eShop 1 80 6 4.9 5.55 M8 eShop eShop eShop eShop eShop 1.25 90 8 6.2 7.45 M10 eShop eShop eShop eShop eShop 1.5 100 10 8 9.35 M12 eShop eShop eShop eShop eShop 1.75 110 9 7 11.2 M16 eShop eShop eShop – – 2 110 12 9 15.1 332
