Режущие и зажимные инструменты Hoffmann Group 2026 - страница 325

GBP 57 G 55° HSS-E- PM h6 DIN Standard 40° 1835 B ≤3×D ​ 13 7810 Synchronised blind hole machine tap C with internal coolant supply 3 Sturdy version with right-hand helix and shank to DIN 1835-B. Special geometry for general-purpose use on machines with synchronised spindle drive. The tap is controlled by the synchronising spindle of the machine. Special TiAlN-S coating for optimum tool life. For use with emulsion (fat content minimum 8%). ​ 13 7813 E 13 7813 – Form E (lead chamfer: 1.5 - 2 turns) for the deepest possible thread depths. 13 7816 – With internal coolant supply for maximum tool life. 1½ Application: For Whitworth parallel pipe threads DIN-ISO 228/1 (threads that do not form a seal within the connection). Note: For use on synchronised spindles, the GARANT quick-change tapping chuck ​ 13 7816 No. 338100 − 338121 with minimum length adjustment (MLA) ensures C very high process reliability. 3 L ⌀D □ ⌀ DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S N ​ ​ ​ ​ ​ ​ 13 7810–​13 7816 32 32 33 32 20 12 7 11 9 30 ● ● ● ● G 13 7810 13 7813 13 7816 Threads per Thread ⌀ L ⌀ Ds □ Tapping hole ⌀ 11H 11H 11H inch Machine tap for synchronised spindles HSS-E-PM HSS-E-PM HSS-E-PM IC / Form C Form E Form C TiAlN TiAlN TiAlN ​ mm mm mm mm mm G1/8 eShop eShop eShop 28 9.73 90 8 6.2 8.8 G1/4 eShop eShop eShop 19 13.16 100 12 9 11.8 G3/8 eShop eShop eShop 19 16.66 100 12 9 15.25 G1/2 eShop eShop eShop 14 20.96 125 16 12 19 UNC C 60° 2B h9 DIN DIN 371 376 3 ≤ 3/8“ ≥ 7/16“ ​Blind hole machine tap 13 7860 – Sturdy design, with 20° right-hand chip flutes. 13 7868 – HOLEX Clever Tap: Sturdy tap for conventional standard applications. High-quality HSS-E tool material and geometry for steels. HSS-E HSS ​ 13 7860 13 Surface: Bronze-coloured tempered thread profile. 20° ≤2×D Application: For UNC uniform coarse threads ASME − B1.1. ≤ 7/8“ 1“ L ​ 13 7868 ØD HSS-E Ø DS 40° ≤2.5×D Suitable for/ vc [m/min] ISO code N N N N P P P P P H H H H H M M S N ​ ​ ​ ​ ​ 13 7860 13 15 15 ● ○ 13 7868 13 13 12 12 6 ● ● UNC 13 7860 13 7868 Threads per Thread ⌀ L ⌀ Ds □ Tapping hole ⌀ 12H 11H inch HOLEX Clever Tap Machine tap machine tap ​ mm mm mm mm mm 4-40 eShop eShop 40 2.84 56 3.5 2.7 2.35 5-40 eShop – 40 3.17 56 3.5 2.7 2.65 6-32 eShop eShop 32 3.51 56 4 3 2.85 8-32 eShop eShop 32 4.16 63 4.5 3.4 3.5 10-24 eShop eShop 24 4.83 70 6 4.9 3.9 12-24 eShop – 24 5.49 80 6 4.9 4.5 1/4-20 eShop eShop 20 6.35 80 7 5.5 5.1 5/16-18 eShop eShop 18 7.94 90 8 6.2 6.6 3/8-16 eShop eShop 16 9.53 100 9 7 8 7/16-14 eShop eShop 14 11.11 100 8 6.2 9.4 1/2-13 eShop eShop 13 12.7 110 9 7 10.8 9/16-12 eShop – 12 14.29 110 11 9 12.2 5/8-11 eShop eShop 11 15.88 110 12 9 13.5 3/4-10 eShop eShop 10 19.05 125 14 11 16.5 7/8-9 eShop – 9 22.23 140 18 14.5 19.5 1-8 eShop – 8 25.4 160 20 16 22.25 325
