GBP 57 G h9 55° 40° ≤2.5×D ​Blind hole machine tap 13 7806 – HOLEX Pro Tap general-purpose tap. Sturdy design suitable for a wide spectrum of materials. Improved HSS-E tool material with low-friction TiN coating. 13 7807 – With extra long shank. 13 7805 13 7808 – Form E (1.5 - 2 turns lead chamfer). C HSS-E- DIN 13 7805/7808/7807 – GARANT Master Tap Universal taps, designed for use in a wide spectrum of materials PM 5156 3 with high process reliability. ■ HSS-E-PM tool material for maximum wear resistance. ■ Reduced coefficient of friction due to the new high-performance coating. ■ Special geometry for optimum swarf evacuation. Advantage: ​ 13 7808 E 13 7807 – Designed for tapping threads where access is difficult. HSS-E- DIN PM 5156 Application: For Whitworth parallel pipe threads DIN-ISO 228/1 (threads that do not form a seal 1½ within the connection). 13 7807 HSS-E- C PM Standard 3 L 13 7806 ØD C HSS-E DIN 5156 Ø DS 3 Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M K N ​ ​ ​ ​ ​ ​ 13 7805/​7808 30 35 20 30 30 25 12 8 10 8 20 20 ● ● ● 13 7806 24 25 10 24 20 15 8 8 15 ● ● ● 13 7807 24 28 16 24 24 20 10 6 8 6 16 16 ● ● ● G 13 7805 13 7808 13 7807 13 7806 Threads per Thread ⌀ L ⌀ Ds □ Tapping 12I 11I 11I 11I inch hole ⌀ GARANT Master Tap HOLEX Pro Tap machine tap machine tap 13 HSS-E-PM HSS-E-PM extra long HSS-E ​ ​ 13 7805 13 7808 13 7807 ​ ​ ​ HSS-E-PM Form C Form E Form C 13 7806 Form C AlTiX AlTiX AlTiX TiN ​ mm mm mm mm mm mm G1/16 eShop – – – 28 7.72 90 – 6 4.9 6.8 G1/8 eShop eShop eShop eShop 28 9.73 90 180 7 5.5 8.8 G1/4 eShop eShop eShop eShop 19 13.16 100 200 11 9 11.8 G3/8 eShop eShop eShop eShop 19 16.66 100 200 12 9 15.25 G1/2 eShop eShop eShop eShop 14 20.96 125 250 16 12 19 G5/8 eShop – – eShop 14 22.91 125 – 18 14.5 21 G3/4 eShop eShop eShop eShop 14 26.44 140 280 20 16 24.5 G1 eShop eShop eShop eShop 11 33.25 160 280 25 20 30.75 Thread gauges – Volume 2 Our comprehensive ex-stock thread gauge range for many different types of threads and all popular sizes can be found in catalogue Volume 2 – Product Group 48. Thread gauges for non-standard pitches, for left-hand threads and for other thread forms are available on request. 48 6008 48 6100 48 6140 48 6010 324
