GBP 57 MF C 60° DIN h9 13 3 40° ≤2.5×D ​ 13 7160 HSS-E- DIN ISO 2X ​Blind hole machine tap PM 374 6HX 13 7161 – Tolerance class: ISO 3X/6GX. For components which are galvanised or shrink slightly when hardened. 13 7162 – With extra long shank. ​ 13 7161 13 7170 – HOLEX Pro Tap general-purpose tap. HSS-E- DIN ISO 3X Sturdy design suitable for a wide spectrum of materials. PM 374 6GX Improved HSS-E tool material with low-friction TiN coating. 13 7160–7162 – GARANT Master Tap Universal taps, designed for use in a wide spectrum of materials with high process reliability. ■ HSS-E-PM tool material for maximum ​ 13 7162 wear resistance. HSS-E- ISO 2X ■ Reduced coefficient of friction due to the PM Standard 6HX new high-performance coating. ■ Special geometry for optimum swarf evacuation. Advantage: 13 7162 – Designed for tapping threads where access is difficult. ​ 13 7170 HSS-E DIN ISO 2 374 6H L ØD Ø DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M K N ​ ​ ​ ​ ​ ​ 13 7160/​7161 30 35 20 30 30 25 12 8 10 8 20 20 ● ● ● 13 7162 24 28 16 24 24 20 10 6 8 6 16 16 ● ● ● 13 7170 24 25 10 24 20 15 8 8 15 ● ● ● MF 13 7160 13 7161 13 7162 13 7170 L ⌀ Ds □ Tapping hole 12I 11I 11I 11I ⌀ GARANT Master Tap HOLEX Pro Tap machine tap machine tap 13 HSS-E-PM 6HX HSS-E-PM 6GX extra long HSS-E-PM HSS-E 6H 13 7160 13 7161 13 7162 ​ ​ ​ 6HX 13 7170 AlTiX AlTiX AlTiX TiN mm mm mm mm mm 2,5×0,35 eShop – – – 50 – 1.8 – 2.15 2,6×0,35 eShop – – – 50 – 1.8 – 2.25 3×0,35 eShop – – eShop 56 – 2.2 – 2.65 3,5×0,35 eShop – – – 56 – 2.2 – 3.15 4×0,35 eShop – – – 63 – 2.8 2.1 3.65 4×0,5 eShop – – eShop 63 – 2.8 2.1 3.5 4,5×0,5 eShop – – – 70 – 3.5 2.7 4 5×0,5 eShop eShop – eShop 70 – 3.5 2.7 4.5 6×0,5 eShop – – eShop 80 – 4.5 3.4 5.5 6×0,75 eShop eShop – eShop 80 – 4.5 3.4 5.2 6,5×0,75 eShop – – eShop 80 – 5.5 4.3 5.8 7×0,5 eShop – – – 80 – 5.5 4.3 6.5 8×0,75 eShop – – eShop 80 – 6 4.9 7.2 8×1 eShop eShop eShop eShop 90 180 6 4.9 7 9×1 eShop – – – 90 – 7 5.5 8 10×0,75 eShop – – – 90 – 7 5.5 9.25 10×1 eShop eShop eShop eShop 90 180 7 5.5 9 10×1,25 eShop – eShop eShop 100 200 7 5.5 8.8 11×1 eShop – – – 90 – 8 6.2 10 12×0,5 eShop – – – 100 – 9 7 11.5 12×0,75 eShop – – – 100 – 9 7 11.25 12×1 eShop eShop – eShop 100 – 9 7 11 12×1,25 eShop – eShop eShop 100 200 9 7 10.8 12×1,5 eShop eShop eShop eShop 100 200 9 7 10.5 13×1 eShop – – – 100 – 11 9 12 14×1,5 eShop eShop – eShop 100 – 11 9 12.5 16×1,5 eShop eShop eShop eShop 100 200 12 9 14.5 18×1 eShop – – – 110 – 14 11 17 18×1,5 eShop – – eShop 110 – 14 11 16.5 20×1,5 eShop – eShop eShop 125 250 16 12 18.5 20×2 eShop – – – 140 – 16 12 18 22×1,5 eShop – – eShop 125 – 18 14.5 20.5 24×1,5 eShop – – eShop 140 – 18 14.5 22.5 24×2 eShop – – – 140 – 18 14.5 22 26×1,5 eShop – – eShop 140 – 18 14.5 24.5 30×1,5 eShop – – eShop 150 – 22 18 28.5 318
