GBP 57 MF 60° HSS-E- PM DIN 13 ISO 2X 6HX h6 DIN Standard 40° 1835 B ≤3×D Synchronised blind hole machine tap with internal coolant supply Sturdy version with right-hand helix and shank to DIN 1835-B. Special geometry for general-purpose use on machines with synchronised spindle drive. The tap is controlled by the synchronising spindle of the machine. C 13 7180 Special TiAlN-S coating for optimum tool life. For use with emulsion (fat content minimum 8%). 3 13 7183 – Form E (lead chamfer: 1.5 - 2 turns) for the deepest possible thread depths. 13 7186 – With internal coolant supply for maximum tool life. Note: For use on synchronised spindles, the GARANT quick-change tapping chuck E 13 7183 No. 338100 − 338121 with minimum length adjustment (MLA) ensures 1½ very high process reliability. C 13 7186 3 L ⌀D □ ⌀ DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S N ​ ​ ​ ​ ​ ​ 13 7180–​13 7186 32 32 33 32 20 12 7 11 9 30 ● ● ● ● MF 13 7180 13 7183 13 7186 L ⌀ Ds □ Tapping hole ⌀ 11H 11H 11H Machine tap for synchronised spindles HSS-E-PM HSS-E-PM HSS-E-PM IC / Form C Form E Form C TiAlN TiAlN TiAlN mm mm mm mm 8×1 eShop eShop eShop 90 8 6.2 7 10×1 eShop eShop eShop 90 10 8 9 10×1,25 eShop eShop eShop 100 10 8 8.8 12×1 eShop eShop eShop 100 12 9 11 12×1,25 eShop eShop eShop 100 12 9 10.8 12×1,5 eShop eShop eShop 100 12 9 10.5 14×1,5 eShop eShop eShop 100 12 9 12.5 16×1,5 eShop eShop eShop 100 12 9 14.5 20×1,5 eShop eShop eShop 125 16 12 18.5 13 MF-LH C 60° HSS-E- DIN DIN ISO 2X h9 PM 374 13 6HX 3 40° ≤2.5×D GARANT Master Tap blind hole machine tap, left-hand thread Universal taps, designed for use in a wide spectrum of materials with high process reliability. ■ HSS-E-PM tool material for a high degree of wear resistance. ■ Reduced coefficient of friction due to the new high-performance coating. 13 7190 ■ Special geometry for optimum swarf evacuation. L ØD Ø DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M K N ​ ​ ​ ​ ​ ​ 13 7190 30 35 20 30 30 25 12 8 10 8 20 20 ● ● ● MF-LH 13 7190 L ⌀ Ds □ Tapping hole ⌀ 11I GARANT Master Tap machine tap Left-hand thread AlTiX mm mm mm mm 8×1 eShop 90 6 4.9 7 10×1 eShop 90 7 5.5 9 10×1,25 eShop 100 7 5.5 8.8 12×1,25 eShop 100 9 7 10.8 12×1,5 eShop 100 9 7 10.5 16×1,5 eShop 100 12 9 14.5 20×1,5 eShop 125 16 12 18.5 24×1,5 eShop 140 18 14.5 22.5 319
