GBP 57 M HSS-E DIN ISO 2 h9 60° 13 6H 40° ≤3×D GARANT Vap Tap blind hole machine tap GARANT Vap Tap general-purpose tap. Can be used reliably in a wide range of materials. Optimised neck and flute length for improved chip evacuation when working on deep threads. High-performance HSS-E tool material with higher vanadium content for improved wear resistance. C 13 5805 DIN DIN Surface vaporised for reduced edge build-up. 371 376 3 13 5805/5810/5840 – Form C (2−3 turns lead chamfer). ≤ M10 ≥ M12 13 5810 – Shank to DIN 376 (shank ⌀ relieved); thus suitable for greater operating depths. 13 5815 – Form E (1.5−2 turns lead chamfer). 13 5840 – With extra long shank. 13 5840 Size M3–M10 – Shank to DIN 371. C 13 5810 13 5840 Size M12–M20 – Shank to DIN 376. DIN 376 Advantage: 3 13 5840 – Designed for tapping threads where access is difficult. E 13 5815 DIN DIN 371 376 1½ ≤ M10 ≥ M12 NEW C 13 5840 DIN DIN Standard 371 376 3 ≤ M10 ≥ M12 L ØD Ø DS 13 Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S N ​ ​ ​ ​ ​ ​ 13 5805–​13 5815 18 13 18 15 15 6 6 15 ● ● ● 13 5840 13 10 14 11 11 4 4 11 ● ● ● M 13 5805 13 5810 13 5815 13 5840 Thread pitch L ⌀ Ds □ Tapping hole 13V 13V 13V 13V ⌀ GARANT Vap Tap machine tap ​ 13 5805 13 5840 13 5805 13 5810 13 5805 13 5810 ​ Form C Form C Form C Form E 13 5810 13 5815 13 5815 DIN 376 extra long 13 5815 13 5840 13 5840 vaporised vaporised vaporised vaporised mm mm mm mm mm mm mm mm M1,6 eShop – – – 0.35 40 – 2.5 – 2.1 – 1.25 M2 eShop – – – 0.4 45 – 2.8 – 2.1 – 1.6 M2,5 eShop – – – 0.45 50 – 2.8 – 2.1 – 2.05 M3 eShop eShop eShop eShop 0.5 56 112 3.5 2.2 2.7 – 2.5 M3,5 eShop – – – 0.6 56 – 4 – 3 – 2.9 M4 eShop eShop eShop eShop 0.7 63 112 4.5 2.8 3.4 2.1 3.3 M5 eShop eShop eShop eShop 0.8 70 125 6 3.5 4.9 2.7 4.2 M6 eShop eShop eShop eShop 1 80 125 6 4.5 4.9 3.4 5 M7 eShop – – – 1 80 – 7 – 5.5 – 6 M8 eShop eShop eShop eShop 1.25 90 140 8 6 6.2 4.9 6.8 M10 eShop eShop eShop eShop 1.5 100 160 10 7 8 5.5 8.5 M12 eShop – eShop eShop 1.75 110 180 9 – 7 – 10.2 M14 eShop – – – 2 110 – 11 – 9 – 12 M16 eShop – eShop eShop 2 110 220 12 – 9 – 14 M18 eShop – – – 2.5 125 – 14 – 11 – 15.5 M20 eShop – eShop eShop 2.5 140 280 16 – 12 – 17.5 M22 eShop – – – 2.5 140 – 18 – 14.5 – 19.5 M24 eShop – – – 3 160 – 18 – 14.5 – 21 M27 eShop – – – 3 160 – 20 – 16 – 24 M30 eShop – – – 3.5 180 – 22 – 18 – 26.5 M33 eShop – – – 3.5 180 – 25 – 20 – 29.5 M36 eShop – – – 4 200 – 28 – 22 – 32 308
