GBP 57 UNF B 60° h9 4 ≤3×D 13 3410 ​Through hole machine tap HSS-E- DIN DIN PM 2BX 371 374 13 3410 – GARANT Master Tap general-purpose tap, designed for use on a wide ≤3/8" ≥7/16" spectrum of materials with high process reliability. ■ HSS-E-PM tool material for maximum wear resistance. ■ Reduced coefficient of friction due to the new high-performance coating. ■ Special geometry for optimum swarf evacuation. 13 3425 – HOLEX Pro Tap general-purpose tap. Sturdy design suitable for a wide spectrum of materials. Improved HSS-E tool material with low-friction 13 3425 TiN coating. HSS-E 2B DIN DIN Application: For UNF unified fine threads ASME − B1.1. 371 374 ≤1/4" ≥5/16" L ØD Ø DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M K N ​ ​ ​ ​ ​ ​ 13 3410 30 35 20 30 30 25 12 8 10 8 20 20 ● ● ● 13 3425 24 25 10 24 20 15 8 8 15 ● ● ● UNF 13 3410 13 3425 Threads Thread ⌀ L ⌀ Ds □ Tapping hole 12I 11I per inch ⌀ GARANT Master Tap HOLEX Pro Tap machine tap machine tap HSS-E-PM HSS-E ​ ​ ​ 13 3410 13 3425 13 3410 13 3425 ​ AlTiX TiN ​ mm mm mm mm mm mm mm 2-64 eShop – 64 2.18 45 2.8 – 2.1 – 1.85 3-56 eShop – 56 2.51 50 2.8 – 2.1 – 2.15 4-48 eShop – 48 2.84 56 3.5 – 2.7 – 2.4 5-44 eShop – 44 3.17 56 3.5 – 2.7 – 2.7 6-40 eShop – 40 3.51 56 4 – 3 – 2.95 8-36 eShop – 36 4.16 63 4.5 – 3.4 – 3.5 10-32 eShop eShop 32 4.83 70 6 6 4.9 4.9 4.1 1/4-28 eShop eShop 28 6.35 80 7 7 5.5 5.5 5.5 5/16-24 eShop eShop 24 7.94 90 8 6 6.2 4.9 6.9 13 3/8-24 eShop eShop 24 9.53 90 10 7 8 5.5 8.5 7/16-20 eShop eShop 20 11.11 100 8 8 6.2 6.2 9.9 1/2-20 eShop eShop 20 12.7 100 9 9 7 7 11.5 9/16-18 eShop eShop 18 14.29 100 11 11 9 9 12.9 5/8-18 eShop eShop 18 15.88 100 12 12 9 9 14.5 3/4-16 eShop eShop 16 19.05 110 14 14 11 11 17.5 7/8-14 eShop eShop 14 22.23 125 18 18 14.5 14.5 20.4 1-12 eShop – 12 25.4 140 18 – 14.5 – 23.25 Pg D 80° DIN DIN h9 HSS-E HSS 40432 40430 4 ≤3×D ≤3×D ≤PG16 PG21 Steel conduit tap Application: For use as machine tap or for cleaning existing threads by hand. L For steel conduit threads DIN 40430. Note: Shank produced according to DIN 40432. ØD Ø DS 13 3450 Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S N N ​ ​ ​ ​ ​ 13 3450 13 15 15 6 13 ● ○ PG 13 3450 Threads per inch Thread ⌀ L ⌀ Ds □ Tapping hole ⌀ 11H Steel conduit tap ​ mm mm mm mm mm PG7 eShop 20 12.5 70 9 7 11.4 PG9 eShop 18 15.2 70 12 9 14 PG11 eShop 18 18.6 80 14 11 17.25 PG13,5 eShop 18 20.4 80 16 12 19 PG16 eShop 18 22.5 80 18 14.5 21.25 PG21 eShop 16 28.3 90 20 16 27 296
