GBP 57 MF D Solid 60° carbide DIN DIN ISO 2X h6 371 13 6HX 4 ≤1.5×D ≤2×D Solid carbide machine tap for through and blind holes Particularly sturdy version. For the highest performance demands. Recommendation: For very hard steels, TOOLOX and HARDOX materials we recommend deviating from the DIN data (see table) by drilling the tapping hole ⌀ 0.05 to 0.3mm larger. ​ 13 2862 For use only with a length compensation chuck − even on machines with synchronised spindle drives. L ØD Ø DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H H H H M N ​ ​ ​ ​ ​ 13 2862 3 2 1 1 5 4 3 18 ● MF 13 2862 L ⌀ Ds □ Tapping hole ⌀ 11H Solid carbide machine tap TiAlN mm mm mm mm 8×1 eShop 90 8 6.2 7 10×1 eShop 100 10 8 9 12×1,5 eShop 110 12 9 10.5 MF B 60° DIN DIN ISO 2X h9 374 13 6HX 4 ≤3×D Through hole machine tap for stainless steels HSS-E 13 2870 13 2870 – Strong spiral point. Guide section with oil grooves. HSS-E- 13 2875 – GARANT Master Tap INOX: PM Powerful tap, specially developed for tapping to high process reliability in 13 2875 stainless and acid-resistant steels and also duplex materials. ■ HSS-E-PM tool material for maximum wear resistance ■ The latest generation of TiALN multi-layer coating ■ Parameterised flute geometry for optimum chip formation and torsional rigidity L 13 ØD Ø DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S N N ​ ​ ​ ​ ​ 13 2870 13 15 15 15 6 13 ● ● 13 2875 28 23 23 12 11 9 ● ● MF 13 2870 13 2875 L ⌀ Ds □ Tapping hole ⌀ 11H 11I GARANT Master Tap INOX Machine tap machine tap HSS-E HSS-E-PM vaporised TiAlN mm mm mm mm 4×0,5 eShop eShop 63 2.8 2.1 3.5 5×0,5 eShop eShop 70 3.5 2.7 4.5 6×0,5 – eShop 80 4.5 3.4 5.5 6×0,75 eShop eShop 80 4.5 3.4 5.2 8×0,75 eShop eShop 80 6 4.9 7.2 8×1 eShop eShop 90 6 4.9 7 10×1 eShop eShop 90 7 5.5 9 10×1,25 eShop eShop 100 7 5.5 8.8 12×1 eShop eShop 100 9 7 11 12×1,25 eShop eShop 100 9 7 10.8 12×1,5 eShop eShop 100 9 7 10.5 14×1,5 eShop eShop 100 11 9 12.5 16×1,5 eShop eShop 100 12 9 14.5 18×1,5 eShop eShop 110 14 11 16.5 20×1,5 eShop eShop 125 16 12 18.5 22×1,5 eShop eShop 125 18 14.5 20.5 24×1,5 eShop eShop 140 18 14.5 22.5 26×1,5 – eShop 140 18 14.5 24.5 30×1,5 – eShop 150 22 18 28.5 285
