GBP 57 M DIN h9 HSS-E ISO 1 ISO 2 60° 13 HSS 4H 6H ≤ M24 ≥ M27 ≤ M1.4 ≥ M1.6 ​Through hole machine tap With spiral point. 13 1150 – Size M2.3 and M2.6 to old DIN profile. 13 1200 – All sizes: Shank to DIN 376(= shank ⌀ tapered), thus B suitable for greater operating depths DIN 371 Sizes M2; M2.5; M3 without square. 4 ≤3×D 13 1150 13 1250 – (Form C) 2−3 turns chamfer lead − without spiral point. Can also be used for blind holes. With TiN coating for: B ■ Improved wear properties. DIN 376 ■ Lower tendency to edge build-up. 4 ≤3×D ■ Higher cutting speeds possible. 13 1200 For use with emulsion (fat content minimum 8%). 13 1265 – HOLEX Clever Tap: Sturdy tap for conventional standard applications. C DIN DIN High-quality HSS-E tool material and geometry for 371 376 3 ≤2×D steels. Surface: Bronze-coloured tempered thread 13 1250 profile. ≤ M10 ≥ M12 B DIN DIN 371 376 4 ≤3×D 13 1265 ≤ M10 ≥ M12 L ØD Ø DS Suitable for/ vc [m/min] ISO code N N N N P P P P P H H H H H M M S N ​ ​ ​ ​ ​ 13 1150/​1200 13 15 15 ● ○ 13 1250 16 20 19 ● ● 13 1265 13 13 12 12 6 ● ● M 13 1150 13 1200 13 1250 13 1265 Thread pitch L ⌀ Ds □ Tapping hole 12H 11H 11H 11H ⌀ Machine tap HOLEX Clever Tap machine tap 13 ​ ​ 13 1150 13 1200 13 1150 13 1200 ​ Form B Form B Form C Form B 13 1250 13 1250 DIN 371 DIN 376 DIN 371/376 DIN 371/376 13 1265 13 1265 TiN mm mm mm mm mm mm mm M1 eShop – – – 0.25 40 2.5 – 2.1 – 0.75 M1,2 eShop – – – 0.25 40 2.5 – 2.1 – 0.95 M1,4 eShop – – – 0.3 40 2.5 – 2.1 – 1.1 M1,6 eShop – – – 0.35 40 2.5 – 2.1 – 1.25 M1,7 eShop – – – 0.35 40 2.5 – 2.1 – 1.3 M1,8 eShop – – – 0.35 40 2.5 – 2.1 – 1.45 M2 eShop eShop – – 0.4 45 2.8 1.4 2.1 – 1.6 M2,2 eShop – – – 0.45 45 2.8 – 2.1 – 1.75 M2,3 eShop – – – 0.4 45 2.8 – 2.1 – 1.9 M2,5 eShop eShop – – 0.45 50 2.8 1.8 2.1 – 2.05 M2,6 eShop – – – 0.45 50 2.8 – 2.1 – 2.1 M3 eShop eShop eShop eShop 0.5 56 3.5 2.2 2.7 – 2.5 M3,5 eShop – – – 0.6 56 4 – 3 – 2.9 M4 eShop eShop eShop eShop 0.7 63 4.5 2.8 3.4 2.1 3.3 M5 eShop eShop eShop eShop 0.8 70 6 3.5 4.9 2.7 4.2 M6 eShop eShop eShop eShop 1 80 6 4.5 4.9 3.4 5 M7 eShop – – – 1 80 7 – 5.5 – 6 M8 eShop eShop eShop eShop 1.25 90 8 6 6.2 4.9 6.8 M10 eShop eShop eShop eShop 1.5 100 10 7 8 5.5 8.5 M12 – eShop eShop eShop 1.75 110 9 9 7 7 10.2 M14 – eShop eShop – 2 110 11 11 9 9 12 M16 – eShop eShop eShop 2 110 12 12 9 9 14 M18 – eShop – – 2.5 125 – 14 – 11 15.5 M20 – eShop eShop eShop 2.5 140 16 16 12 12 17.5 M22 – eShop – – 2.5 140 – 18 – 14.5 19.5 M24 – eShop eShop eShop 3 160 18 18 14.5 14.5 21 M27 – eShop – – 3 160 – 20 – 16 24 M30 – eShop eShop – 3.5 180 22 22 18 18 26.5 M33 – eShop – – 3.5 180 – 25 – 20 29.5 M36 – eShop eShop – 4 200 28 28 22 22 32 265
