GBP 57 Type 37 5300 37 5305 37 5301 37 5306 37 5310 T-slot nomi- Thread G Length L b a e k 32H 32H 35A 35A 35A nal size Tee bolt (10.9. / 8.8.) Tee bolt (8.8.) Tee bolt (12.9.) ​ ​ ​ 37 5300 37 5301 ​ ​ ​ 37 5305 37 5306 37 5310 complete single complete single single mm ​ mm mm mm mm mm mm 2220110 – – eShop eShop – 20 M20 110 – 70 21.7 35 14 2220125 eShop eShop – – eShop 22 M20 125 85 – 21.7 35 14 2220150 – – eShop eShop – 20 M20 150 – 95 21.7 35 14 2220200 eShop eShop – – eShop 22 M20 200 125 – 21.7 35 14 2220215 – – eShop eShop – 22 M20 215 – 125 21.7 35 14 2220315 eShop eShop – – eShop 22 M20 315 190 – 21.7 35 14 2424125 – – eShop eShop – 24 M24 125 – 75 23.7 40 16 2424150 – – eShop eShop – 24 M24 150 – 95 23.7 40 16 2424160 eShop eShop – – eShop 24 M24 160 110 – 23.7 40 16 2424210 – – eShop eShop – 24 M24 210 – 130 23.7 40 16 2824100 eShop eShop – – (eShop) 28 M24 100 70 – 27.7 44 18 2824110 – – eShop eShop – 28 M24 110 – 65 27.7 44 18 2824150 – – eShop eShop – 28 M24 150 – 95 27.7 44 18 2824160 eShop eShop – – eShop 28 M24 160 110 – 27.7 44 18 2824210 – – eShop eShop – 28 M24 210 – 130 27.7 44 18 2824250 eShop eShop eShop eShop eShop 28 M24 250 150 170 27.7 44 18 2824400 eShop eShop – – eShop 28 M24 400 240 – 27.7 44 18 4236250 – eShop – – – 42 M36 250 175 – 41.6 65 26 ​T-nuts Standard: 37 5315/5320 – DIN 508 Material: 37 5315 – Quenched and tempered steel, strength 10. 37 5316 – Hardened, black. 37 5315​ ​37 5320 37 5320 – Quenched and tempered steel, unhardened (= blank, without thread). Application: a 37 5320 – Blanks for production of T-nuts with non-standard threads. 37 5315/5316 – For combination with studs or bolts. k Note: Full load-bearing capacity only when threaded for the entire nut length. e 37 5316 a k e T-slot nominal 37 5315 37 5316 37 5320 Thread Nut height Width a Width e Height k 32H 35A 35A size T-nut 37 5315 ​ ​ ​ ​ 37 5316 with thread with thread Blank mm ​ mm mm mm mm 6 eShop – eShop M5 8 5.7 10 4 8 eShop eShop eShop M6 10 7.7 13 6 10 eShop eShop eShop M8 12 9.7 15 6 12/M8 – eShop – M8 14 11.7 18 7 12 eShop eShop eShop M10 14 11.7 18 7 14/M8 – eShop – M8 16 13.7 22 8 14/M10 – eShop – M10 16 13.7 22 8 14 eShop eShop eShop M12 16 13.7 22 8 16/M12 – eShop – M12 18 15.7 25 9 16 eShop eShop eShop M14 18 15.7 25 9 37 18/M10 18/M12 18 – – eShop eShop eShop eShop – – eShop M10 M12 M16 20 20 20 17.7 17.7 17.7 28 28 28 10 10 10 20 eShop – eShop M18 24 19.7 32 12 22/M16 – eShop – M16 28 21.7 35 14 22 eShop eShop eShop M20 28 21.7 35 14 24 eShop – eShop M22 32 23.7 40 16 28/M20 – eShop – M20 36 27.7 44 18 28 eShop eShop eShop M24 36 27.7 44 18 32 eShop – – M27 40 31.6 50 20 36 eShop – – M30 44 35.6 54 22 1240
