GBP 57 ​ High precision tenons for aligning appliances and tools Precision ground all round, resulting in quick alignment times for appliances, vices etc., which are to be aligned parallel to the table slots of machine tools. A dial indicator is thus no longer required. Material: Steel C 15, case-hardened. 375365 Stepped fixed tenons for screw attachment Accuracy: Dimension b = fit h6. Application: These T-nuts are screwed in pairs into the standard 20 mm-wide tenon slots of jigs. By changing the T-nuts it is possible to work on several machines with different slot widths with one jig each. Jig Screw DIN 912 Note: Size 20 see No. 375370 Tenon Machine table Slot size b1 37 5365 Slot size b2 for screws Length Height Slot size b1 37 5365 Slot size b2 for screws Length Height 35A 35A of the machine of the jig DIN 84, DIN 912 H of the machine of the jig DIN 84, DIN 912 H Stepped tenon Stepped tenon ground ground mm mm ​ mm mm mm mm ​ mm mm 10 eShop 20 M6×10 22 10 18 eShop 20 M6×16 25 10 12 eShop 20 M6×10 22 10 22 eShop 20 M6×16 32 12 14 eShop 20 M6×16 25 10 24 (eShop) 20 M6×16 32 12 16 eShop 20 M6×16 25 10 28 eShop 20 M6×16 32 12 Flat tenons for screw attachment ​ Accuracy: Dimension b = fit h6. Application: Flat tenons are appropriate when a vice is always used on a machine with the same slot width. 375370​ Jig Screw DIN 912 Tenon Machine table Slot size b1 37 5370 for screws Length Height Slot size b1 37 5370 for screws Length Height 35A 35A of the machine DIN 84, DIN 912 H of the machine DIN 84, DIN 912 H and jig and jig Flat tenon ground Flat tenon ground mm ​ mm mm mm ​ mm mm 10 eShop M4×10 20 8 18 eShop M6×16 22 10 12 eShop M5×12 20 8 20 eShop M6×16 22 10 14 eShop M6×16 22 10 22 eShop M6×16 32 12 16 eShop M6×16 22 10 24 (eShop) M6×16 32 12 Loose tenons for adjustment ​ Standard: DIN 6323 Application: These loose tenons are inserted sideways into the slots after rough alignment of the fixture. When transporting the fixture, there are then no tenons protruding underneath and the table cannot be damaged. 2 pieces are sufficient per machine, or 4 pieces for a double set-up. _12/20 − 18 _12/12 _22 − 28 b2 b2 = 12 b2 = 20 H1 H H1 H1 2 0,02 H 0,0 b1 02 0, b1 = 12 b1 Slot size b1 37 5375 Slot size b2 Height Height Length 35A 37 of the machine mm Loose tenon ground for adjustment of the jig mm H mm H1 mm mm 10 (eShop) 12 12 3.6 20 12/12 eShop 12 28.6 5.5 20 12/20 eShop 20 14 5.5 32 14 eShop 20 14 5.5 32 16 eShop 20 14 5.5 32 18 eShop 20 14 5.5 32 22 eShop 20 50.5 7 40 28 eShop 20 61.5 7 40 1238
