GBP 57 ​ Manual vices for drilling machines ■ Sturdy design with strong spindle. ■ Jaws through hardened and ground. ■ Precise clamping due to long flat guide. ■ One jaw with horizontal and vertical prismatic profiles for round material, one jaw smooth. ■ Both jaws are stepped at the top to clamp flat parts. 36 5033 – Spindle with external hexagon. 36 5038 – ■ Patent-pending integrated eccentric quick clamping for a secure grip on the drilling machine table. ■ The quick clamping in the area of the grooves makes it possible to process 36 5033 the clamped workpiece flexibly and efficiently at any desired position on the entire drilling machine table without re-clamping. Accuracy: Within 0.10 mm. Material: Body and movable jaw made of special cast iron. Application: For clamping components on drilling machines. Supplied with: 36 5038 – Clamp wrench and three Tee-nuts in sizes 12;14 and 16 mm. 36 5038 Eccentric quick clamping on the underside Open and lock the clamping using Easily and securely clamped for machining. of the vice. the supplied clamp wrench. Jaw width A mm 60 80 100 120 150 36 5033 Manual vice for drilling machines eShop eShop eShop eShop eShop 31S 36 5038 Manual vice for drilling machines, with eccentric quick clamping – – eShop eShop – 31S Clamping range b mm 79 120 143 173 209 Jaw height C mm 25 28 32 40 40 Base body length a mm 169 238 286 340 400 Base body width B mm 115 140 174 193 226 Overall height c (36 5033) mm 55 65 82 90 90 Overall height c (36 5038) mm – – 92 107 – Clamping slot spacing mm 90 110 141 160 189 Clamping slot width mm 13 13 17 17 19 maximum overall length L4 mm 271 280 474 556 652 Weight (36 5033) kg 3.2 5.7 11.7 18 23.8 Weight (36 5038) kg – – 12.5 20 – Colour code for suitable accessories ​ ​ ​ ​ ​ Magnetic jack ■ For use as an additional support point to avoid vibration of the workpiece. ■ Ideal in combination with vices. ■ Simple and accurate positioning for vertical and horizontal clamping. ■ With knurled surface for manual adjustment of height and width across flats, for more positive support. ■ Captive support elements. ■ Point support available in any position. Suitable for: All vices, can be used as a support in all clamping situations. Material: Spring steel Application: For avoiding vibration, especially when clamping thin workpieces. 36 Type 15 36 6745 Magnetic jack eShop 31O H mm 27 – 40 Diameter mm 20 Colour code: DM vice, blue BM vice, grey 1217
