GBP 57 ​ NC high-pressure vice Small size – optimum ratio of clamping range to overall length. Wear-resistant Stepless adjustment – 100% clamping force at 360°. Thread M8 Stepped jaws power intensifier Particularly rigid body made of GJS-60, ground on top and bottom faces. for component backstop Pairing accuracy 0.02 mm. Feature: ■ Fully enclosed low-maintenance nitrided spindle. ■ Increased service reliability. ■ Optimised swarf protection. ■ Minimised cleaning requirement. Application: For horizontal use. Versatile clamping unit for machining centres. Supplied with: Including 2 pcs. stepped jaws and 1 pc. hand crank. Optional extras: Stepless adjustable clamps No. 360579. Alignment and fixing set No. 360530. Popular makes of jaws such as No. 361400– 361660, No. 361295– 361298. Workpiece backstop and crank No. 360555 and 360800. Jaws quick-change system No. 361293 125 and 361294 125. Precise location slots Note: Alignment dimensions not compatible with those of other manufacturers. Outlet opening ​ 36 0565 for chips and coolant Proven low-maintenance high-pressure spindle with constant pressure level due to low-wear fully mechanical power intensifier. No decline of clamping force. L Type 125ST 160ST a 36 0565 NC high-pressure vice eShop eShop n 32P Clamping force up to maximum kN 40 60 Weight kg 33 66 B I L mm 441 573 a mm 398.5 530 B mm 126 164 d b mm 0 – 182 0 – 245 c −0.02 mm 95 110 F mm 134.5 159.8 b d mm 131 – 313 190 – 435 g mm 21 SW l H8 mm 20 F n H7 mm 20 c r mm 128 174 g t mm 62.5 70 t r Colour code for suitable accessories ​ ​ AF mm 14 Stepped jaws ​ Suitable for: NC high pressure vice No. 360565. Material: Hardened, nitrided, both sides smooth. Supplied with: Incl. fastening screws. h1 Type 125 160 Stepped jaws ​ 36 0573 36 0573 eShop eShop 32P movable l1 Stepped jaws 36 0574 eShop eShop 32P fixed b mm 124.4 160.4 h mm 39.5 49.8 h1 mm 20 25 l (36 0573) mm 70 114 l (36 0574) mm 92 104 h1 l1 mm 43 64 suitable for colour code ​ ​ ​ 36 0574 l1 Clamping claws ​ 36 Suitable for: NC high pressure vice No. 360565. for jaw width mm 125/160 Set of clamps 36 0579 eShop 32P 2 pieces suitable for colour code ​ ​ 36 0579 Colour code: HOLEX NC 1196
