Centre jaws piece

36 3040 – With grip serrations in a 3 mm step and a smooth clamping face. 36 3042 – Pre-impression of the serrated contour necessary. With 3 mm grip step and smooth clamping face. 36 3044 – With smooth 3 mm grip step and smooth clamping face.

Suitable for: Spindle bearing, complete No. 363008.

Note: Not for use with size 50 or Xtric types XS and XSP! 36 3040_80

suitable for colour code

Top jaws, offset piece

36 3041 – With grip serrations in a 3 mm step and a smooth clamping face. 36 3043 – Pre-impression of the serrated contour necessary. With 3 mm grip step and smooth clamping face. 36 3045 – With smooth 3 mm grip step and smooth clamping face.

Application: To avoid clamping gaps. See clamping capacity overview. 36 3041_80

Clamping situation with 363041

2

2

l mm 14.5 22.5 28.5

3 suitable for colour code

Double clamping spindle bearing

• Permits the clamping of two components.
• 4 mm length compensation of the spindle for clamping workpieces of different sizes.
• Straightforward assembly and removal.

Suitable for: Separately obtainable centre jaws No. 363040, 363042, 363044.

Supplied with: Spindle bearing, spindle with length compensation.

Optional extras: Hexagon screwdriver No. 627424 size 3 and size 5.

Note: Not for use with size 50 or Xtric types XS and XSP! 36 3008

36

Clamping situation with 36 3008, 36 3040 and 36 3041 reversed.
