Centric clamping to perfection for your automation

Top jaws with optimised contour design 100 % centred Various different top jaws

  • Optional coating for process reliability in machining.
  • Centring adjustment
  • Finished parts are clamped using pairs of parallels.
  • Hardened and underside precision milled. for perfect
  • Raw materials and finished parts are clamped using the same
  • Very good repetition accuracy < 0.01 mm. centring. jaw.

Spindle nut with or without pivot function Clamping jaw quick-change system The size code P stands for pivoting jaw. Clamping jaw quick-change The pivot function nut permits pivoting by ± 2°. in seconds Use of the pivot function nut offers increased security without tools by clicking for components such as sawn parts. onto the Greater precision when using rigid version. dovetailed slide.

Chromium-plated spindle Different base lengths

  • Linear clamping force development
  • Choose the right length for every machine. – XTRIC50: 40 Nm generate 16 kN clamping force

– XTRIC80: 85 Nm generate 25 kN clamping force Clamping edge – XTRIC125: 132 Nm generate 32 kN clamping force

  • Internal clamping available by switching the spindle nuts.
  • Perfect for clamping claws.

Laser-engraved graduations

  • For pre-positioning the clamping jaws.

Interface for automated applications Centring adjustment Longitudinal slots with pin wrench

  • Freely usable interface.
  • Also serves as a cleaning opening.
  • Quick and easy alignment on the machine tool table.
  • Also serves as an endutec interface
  • Size 50H suitable for Häberle automation systems.
  • Size 50XSE suitable for Erowa ITS50.
  • With 363085 148P adaptable to Erowa ITS148.

Special underside

  • Hole pattern suitable for the “LANG” positioning system. (Grid scale XTRIC 50 and 80: 52 mm; XTRIC125: 96 mm)
  • Can be clamped to the GARANT ZeroClamp using the adapter.

The clamping jaw quick-change system: for more clamping options

50XS 50H50S 80XS 80S 80M 80SMT125XS 125S 125M 125L125XL
(XSE)(SP)(XSP)(SP)(MP)(XSP)(SP)(MP)(LP)(XLP)
Standard0 – 220 – 360 – 510 – 42 0 – 76 0 – 126 0 – 1010 – 600 – 940 – 1440 – 1940 – 244
Reversed49 – 6549 – 7949 – 94 74 – 110 74 – 144 74 – 194 74 – 169 92 – 14692 – 18092 – 23092 – 28092 – 330
Offset jaws20 – 3620 – 5020 – 6529 – 65 29 – 9929 – 14929 – 12435 – 8935 – 12335 – 17335 – 23235 – 273

Offset jaws,

reversed 35 – 51 35 – 65 35 – 80 51 – 87 51 – 121 51 – 171 51 – 146 63 – 117 63 – 151 63 – 201 63 – 251 63 – 301

Centre jaw,

standard* – – – – 6 – 29.5 6 – 54.5 6 – 42 – 6 – 37 6 – 62 6 – 87 6 – 112

Centre jaw,

reversed* – – – – 40 – 63.5 40 – 88.5 40 – 76 – 49 – 80 49 – 105 49 – 130 49 – 155

Centre jaw,

offset jaws* – – – – 17.5 – 41 17.5 – 66 17.5 – 53.5 – 20.5 – 51.5 20.5 – 76.5 20.5 – 101.5 20.5 – 126.5

Centre jaw,

36 offset jaws, – – – – 28.5 – 52 28.5 – 77 28.5 – 64.5 – 34.5 – 55.5 34.5 – 90.5 34.5 – 115.5 34.5 – 140.5

reversed* 1 pc. standard,

1 pc. reversed** 27.5 – 43.5 27.5 – 57.5 27.5 – 72.5 35 – 101 35 – 135 35 – 185 35 – 160 49 – 103 49 – 137 49 – 187 49 – 237 49 – 287

1 pc. offset jaw,

1 pc. offset jaw, 27.5 – 43.5 27.5 – 57.5 27.5 – 72.5 40 – 76 40 – 110 40 – 160 40 – 135 49.5 – 103.5 49.5 – 137.5 49.5 – 187.5 49.5 – 237.5 49.5 – 287.5

reversed** * for each clamping point ** no longer a centring vice
