ZeroClamp, adapted clamping system for 3/5-axis machines

(according to machine type)

Centre bore ⌀ 25 H7 to take the centring set. es,

Material: Base plate of high-tensile aluminium, surface treated. ecial siz

All components of the clamping pot of stainless or corrosion- al solutions and spot ⌀ 138 mm,

resistant steel. Individu y type of machine S

Optional extras: Clamping stud No. 360025, even for clamping p available for an connection blocks No. 360017 size 12808 and size 12805.

Note: Depending on the machine type, the arrangement may differ ⌀ A B

from that in the illustration.

H 36 0014

Base with cross pitch for higher support torque and other clamping applications (centre)

Type 14014 10089 10477 29612 29598

36 0014 ZeroClamp base plate

(eShop) (eShop) (eShop) (eShop) (eShop)

(depending on the machine type / machine table)

suitable for machine type MAZAK VARIAX 500 DMG DMU 50 Mazak Variax 630 Hermle C 32 DMG DMU 60eV0

Clamping pot ⌀ mm 120

Cover plates for base plates (based on machine type)

The cover plates are made of 1 mm stainless steel 1.4301 for covering the base units. (protect the surface + cover the location holes.) 36 0021_11648

ZeroClamp extension bases / adapters

1-pot extension bases

Clamping pot ⌀ 120 mm, indexed.

Suitable for: For base plates with pitch 200. H H

Supplied with: Including coupling plug and clamping stud No. 360025 size 18M16.

Optional extras: Quick-release coupling No. 360019 size 10241 and size 1003. B B _12810 _12281

2-pot extension bases

With 2 clamping pots.

Suitable for: For base plates with pitch 200. H

Supplied with: Including coupling plug and clamping stud No. 360025 size 18M16.

Optional extras: Quick-release coupling No. 360019 size 10241 and size 10003. H

36 Note: Consoles with clamping pot dia. 138 mm are also available with

self-locking clamping pots on request! _12732 _12736
