Assembly wrench for ball nozzle

Application: Ball nozzles with M12×1 threaded ring.

31 9008

Type 4

31 9008 Assembly wrench for ball nozzle eShop

For targeted cooling and lubrication on the cutting edge/evacuation of chips.

Application: In holders with M12×1 thread.

Supplied with: Ball, threaded ring and sealing ring.

Optional extras: Assembly wrench for ball nozzle No. 319008 4.

31 9005

Contact point ⌀ 10

31 9005 Ball nozzle installation set eShop 1

Application: In VDI arbors in ball type coolant nozzles with metric threads.

31 9115

31 9118 31

Type				3,5×50	5×50	5×100	6×50	6×100
	31 9115	VDI coolant pipe, copper		eShop	eShop	eShop	eShop	eShop
	31 9118	VDI coolant pipe, stainless steel (V2A)		eShop	eShop	eShop	eShop	eShop
Thread size				M3.5	M5	M5	M6	M6
Overall length			mm	50	50	100	50	100

Colour code for VDI shanks
