Shrink-fit chuck, vibration-damped −

ISO 12164-1 (DIN 69893-1) Vibration damping

• High-temperature steel.
• Integrated length adjustment of the tools.
• For HSS and solid carbide tools.
• Shanks hard turned (smooth cutting action!).
• With RFID/Balluffchip bore.
• With coolant channel bores and threads that can be sealed. 30 8344
• With tapped holes on each side for balancing screws.
• Reinforced version/contour. Carbide core drilled through, mounted in
• Polished surface. an aluminium cylinder – optimum shock Specially mounted carbide core in the shrink-fit chuck body. absorption characteristics!

Advantage: Vibration-damping.

• Better workpiece surface finish.
• Optimised tool life.
• Increased process reliability.
• Lower corrosion tendency due to polished surface.

Application: For clamping tools with plain shank (h6 shank tolerance). Suitable for inductive, contact and hot air shrink-fitting units.

Optional extras: HSK coolant tube No. 309880, A Socket wrench No. 309890, L2 Shrink-fit unit, accessories No. 354210 – 354440, Balancing screws set No. 309906 size 180.

• D2
• D1
• D
• D3

Clamping range D mm 6 8 10 12 16

1 30 8342 HSK-A 63

A = 120 eShop eShop eShop eShop eShop

30 8344 HSK-A 63

Shrink-fit chuck A = 160 eShop eShop eShop eShop eShop

vibration-damped,

30 8346 with cooling channel bores HSK-A 100

A = 120 eShop eShop eShop eShop eShop

30 8348 HSK-A 100

A = 160 eShop eShop eShop eShop eShop

• D mm 6 8 10 12 16 1
• D mm 21 21 24 24 27 2
• D (30 8342, 30 8344) mm 53 3
• D (30 8346, 30 8348) mm 88 3

L (30 8342) mm 57 57 62 62 65

2

L (30 8344) mm 70 70 79 79 79

2

L (30 8346) mm 50 50 60 63 68

2

L (30 8348) mm 60 60 70 70 70

2

DIN Form 69893 A ≤50 bar

Quick-change tapping chucks for synchronised spindles

• With minimum length adjustment (MLA), by means of a damping element.
• Increases tool life of taps by up to 300 %.
• Internal coolant supply up to 50 bar.
• Secure clamping for ER collets in quick-change tapping collets.
• Run-out of shank taper to the tapping collet taper < 3 µm.

Application: On machining centres with synchronised spindles.

• For compensating the difference in pitch between tap/synchronised spindle.
• For compensating the pitch tolerances of taps.

Optional extras: See No. 308600 - 308806 for pull studs. Coolant feed pipes for HSK, see No. 309880. See No. 309890 for plug-in sockets for HSK. D D 1 Quick-change tapping collets and extensions, see No. 338120 – 338142.

33 8110 A 30

Tapping chuck

33 8115 MLA IC 50 bar HSK-A 100 eShop eShop
