GBP 57 TOOL UNIT TOOL CARRIER Portable and safe. Storage Sturdy and hard-wearing e.g. in a Tool UNIT cabinet Wear-resistant PP protects the tool sockets and or tool trolley, is resistant to oils, grease and cooling lubricants. on the Multifix rail. ■ Optimum use of space ■ Multi-point contact prevents the tool shank from sticking. ■ Side access ■ Informative: a labelling field informs the user about the contents. Provision Transport at the machine tool or Modular tool trolley, pre-setting device. CNC tool trolley. ​ Tool UNIT tool carrier Tool carrier A Tool carriers of hard-wearing polypropylene, with sockets for tool shanks. Tool carriers can be used as individual units for transport and storage, but are also very suitable for use as flexible components in a tool trolley or CNC cabinet, CNC racking, and UNIT carrier rail. Size 0 – 30 mm thick PE plate for drilling to suit e. g. collets and tools with shanks. Application: For mounting in carrier rail No. 970110, 970668 and 971270, CNC cabinets No. 971201 and 971203 and Multifix rail No. 928201, 943170 and 955340 (not suitable for No. 955350). 97 1000_C4 for tool shanks SK30 SK40 SK50 VDI20 VDI30 VDI40 C4 C5 C6 C8 97 1000 91Q Tool UNIT tool carrier eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop 97 Height Width mm mm 130 240 Depth mm 148 Number of tool sockets 8 4 2 8 8 4 8 5 4 2 Axial spacing A mm 55 70 120 55 55 68 55 64 71 105 Safe working load kg 20 for tool shanks HSK40 HSK50 HSK63 HSK80 HSK100 0 97 1000 91Q Tool UNIT tool carrier eShop eShop eShop eShop eShop eShop Height mm 130 Width mm 240 Depth mm 148 Number of tool sockets 8 5 3 2 2 – Axial spacing A mm 54 63 70 105 107 – Safe working load kg 20 Labelling strip set Labelling strip set comprising 50 pieces plastic-coated labelling strips, suitable for marker pen. Suitable for: GARANT Tool UNIT No. 971000. 97 5000 Labelling strip set, 50 pieces eShop 91Q Height mm 33 Width mm 210 97 5000 556
