GBP 57 Accessories for tool trolleys and tool block insertion frame Suitable for: Width 452 mm: Modular tool trolley No. 970011; 970016 each in size 452/A; CNC tool trolley No. 970041; 970046 each in size 452; tool block insertion frame No. 970505 size 0. Width 627 mm: Modular tool trolley No. 970011; 970016 each in size 627/A; 627/B; CNC tool trolley No. 970041; 970046 each in size 627. Colour: RAL 7035 light grey powder-coated. Tool UNITS are simply inserted. Carrier rails for GARANT UNITS Made of sheet metal for insertion of GARANT Tool UNIT tool carriers No. 971000. 97 1000_C6 Can be fitted at inclination angles of 0° / 20° / 45°. Supplied with: Without Tool UNIT tool carriers, please order separately under No. 971000. Width mm 452 627 97 0110 Carrier rail for Tool UNIT tool carrier eShop eShop 91L Height mm 55 Width mm 452 627 Depth mm 250 97 0110_627 Number of tool carriers Tool-UNIT 3 4 Tool carrier ​ Made of sheet metal with plastic GARANT tool socket inserts. A Can be fitted at inclination angles of 0° / 20° / 45°. Size 0 – 30 mm thick PE plate for drilling to suit e. g. collets and tools with shanks. Note: VDI 20 sockets also suitable for TRUMPF stamping punches. 97 0130 for tool shanks SK30 SK40 SK50 VDI20 VDI30 VDI40 C4 C5 C6 C8 Width 97 0125 eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop 91L 452 mm Tool carrier with tool sockets Width 97 0130 eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop 91L 627 mm Depth mm 150 lateral frame size mm 37 Number of tool sockets (97 0125) 12 9 4 18 12 9 5 5 4 4 Number of tool sockets (97 0130) 17 13 5 28 17 13 8 8 5 6 Axial spacing A mm 69 85 117 52 69 85 82 82 142 108 for tool shanks HSK40 HSK50 HSK63 HSK80 HSK100 0 Width 97 0125 97 eShop eShop eShop eShop eShop eShop 91L 452 mm Tool carrier with tool sockets Width 97 0130 eShop eShop eShop eShop eShop eShop 91L 627 mm Depth mm 150 lateral frame size mm 37 Number of tool sockets (97 0125) 17 9 9 4 4 – Number of tool sockets (97 0130) 21 14 14 6 5 – Axial spacing A mm 56 76 76 108 111 – TOOL UNIT Advantages: ■ Clear storage: In a UNIT cabinet or tool trolley, on the Multifix rail. ■ On-site provision: At the machine tool or pre-setting device. Quick access, short distances. 548
