Каталог Duemmel общий 2022 - страница 77
Навигация
Общий каталог Dümmel 2014
Каталог Dümmel дополнение 2017
Каталог Dümmel дополнение 2018
Общий каталог Dümmel 2015
grooving, boring and profiling grooving D min. 2.0 mm
starting at Ø 0.2 mm depth of groove t max. 0.4 mm
L
D m
in.
L1
b
Rechts (R): wie gezeichnet righthand (R): as shown Links (L): spiegelbildlich lefthand version (L): mirror image
Abmessungen in mm dimensions in mm
| R/L 002.0050-5 | 0.5 | 1.8 | 19 | 5 | 0.4 | 2.0 | 4.0 | | |
| R/L 002.0050-10 | 0.5 | 1.8 | 24 | 10 | 0.4 | 2.0 | 4.0 | | |
| 640.∙∙∙ 645.∙∙∙ ∙∙∙.4 | |||||||||
| R/L 002.0050-15 | 0.5 | 1.8 | 29 | 15 | 0.4 | 2.0 | 4.0 | |
