| groove milling by circular | for circlip grooves DIN 471 / 472 | D min. 22 mm |
| interpolation | and groove milling general use | t max. ≤ 4.5 |
| DS t max. S X Fräserschaft shank face | b R R | X | Beispiel exempl | m zeichnung ary application |
| Abmessungen in mm Bestellnummer part number D min. Nut-Maß m groove dim. m DIN 471 / DIN 472 S Z22007000 22 07 56 | R Ø DS 217 | dimensions b +0.02 ( b -0.02) 074 | in mm b (inch) t max. 15 | Zähnezahl number of teeth K10F AL41F P18C für Fräserschaft for milling shank 3 |
| .. . . | - . | . | . | |
| Z22.0079.00 22 - - 5.6 Z22.0080.00 22 0.8 5.6 | - 21.7 - 21.7 | 0.79 0.84 | 0.031" 1.5 1.7 | 3 3 |
| Z22.0090.00 22 0.9 5.6 | - 21.7 | 0.94 | 1.9 | 3 |
| Z22.0099.00 22 - - 5.6 | - 21.7 | 0.99 | 0.039" 2.0 | 3 |
| Z22.0100.00 22 1.0 5.6 | - 21.7 | 1.04 | 2.1 | 3 |
| Z22.0100.01 22 - - 5.6 | 0.10 21.7 | 1.00 | 4.5 | ZH22.∙∙∙ 3 |
| Z22.0110.00 22 1.1 5.7 | - 21.7 | 1.21 | 2.5 | 3 |
| Z22.0117.00 22 - - 5.7 | - 21.7 | 1.17 | 0.046" 2.5 | 3 |
| Z22.0130.00 22 1.3 5.7 | 0.10 21.7 | 1.41 | 4.5 | 3 |
| Z22.0142.01 22 - - 5.7 | 0.10 21.7 | 1.42 | 0.056" 4.5 | 3 |
| Z22.0150.02 22 - - 5.7 | 0.20 21.7 | 1.50 | 4.5 | 3 |
| Z22.0160.00 22 1.6 5.7 | 0.10 21.7 | 1.71 | 4.5 | 3 |
| Z22.0185.02 22 1.85 5.7 ↳ ... | 0.20 21.7 | 1.96 | 4.5 | 3 |
