groove milling by circular	for circlip grooves DIN 471 / 472	D min. 22 mm
interpolation	and groove milling general use	t max. ≤ 4.5

DS t max. S X Fräserschaft shank face	b R R	X	Beispiel exempl	m zeichnung ary application
Abmessungen in mm Bestellnummer part number D min. Nut-Maß m groove dim. m DIN 471 / DIN 472 S ... ↴	R Ø DS	dimensions b +0.02 ( b -0.02)	in mm b (inch) t max.	Zähnezahl number of teeth K10F AL41F P18C für Fräserschaft for milling shank
Z22.0198.02 22 - - 5.7 Z22.0200.02 22 - - 5.7 Z22.0215.02 22 2.15 5.7 Z22.0238.02 22 - - 5.7 Z22.0250.02 22 - - 5.7 Z22.0265.02 22 2.65 5.7 Z22.0300.02 22 - - 5.7 Z22.0315.02 22 3.15 5.7 Z22.0350.02 22 - - 5.7 Z22.0400.02 22 - - 5.7 Z22.0415.02 22 4.15 5.7 Z22.0475.02 22 - - 5.7	0.20 21.7 0.20 21.7 0.20 21.7 0.20 21.7 0.20 21.7 0.20 21.7 0.20 21.7 0.20 21.7 0.20 21.7 0.20 21.7 0.20 21.7 0.20 21.7	1.98 2.00 2.26 2.39 2.50 2.76 3.00 3.26 3.50 4.00 4.26 4.75	0.078" 4.5 4.5 4.5 0.094" 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5 0.187" 4.5	3  ZH22.∙∙∙ 3  3  3  3  3  3  3  3  3  3  3 
Z22.0500.02 22 5.7 Z22.0515.02 22 5.15 5.7	0.20 21.7 0.20 21.7	5.00 5.26	4.5 4.5	3  3 
