MIKROMILL Nut- und Formzirkularfräsen	Typ MA4 / MA6 metrisches ISO-Gewinde, Vollprofil, innen	ab Gewi	ndegröße M3 x 0.35
groove milling by circular interpolation	metric ISO-thread, full profile, internal	starting	at thread size M3 x 0.35
L2	L1 D	S	X
d1	d h6		b 60° H1 E
X	Version A / Schaft nach DIN 6535HA version A/shank acc. DIN 6535HA	Beispielze exempla	ichnung ry application
Abmessungen in mm Bestellnummer part number D min. Steigung P pitch P	dimensions in mm min.Gewindegröße min. thread size Feingewinde / fine thread L2 L1 b E H1 Ø d h6	Ø d1	Ø DS Schneidenzahl cutting edge K10F AL41F P18C
MA4.VP035-8 2.4 0.35	M3 8 44 0.04 0.2 0.19 4	1.4	2.0 3 
MA4.VP050-8 2.4 0.5 MA4.VP060-9 2.7 0.6	M3 8 44 0.06 0.3 0.27 4 M3.5 9 44 0.08 0.3 0.33 4	1.25 1.4	2.0 3  2.3 3 
MA6.VP050-10 3.3 0.5 MA6.VP070-10 3.3 0.7	M4 10 58 0.06 0.3 0.27 6 M4 10 58 0.09 0.4 0.38 6	2.0 1.85	2.8 3  2.8 3 
MA6.VP075-16 5.0 0.75	M6 16 68 0.1 0.5 0.41 6	3.1	4.2 4 
MA6.VP080-12 4.1 0.8	M5 12 58 0.09 0.6 0.43 6	2.4	3.6 4 
MA6.VP100-16 5.0 1.0 MA6.VP125-16 6.5 1.25	M6 16 68 0.12 0.6 0.54 6 M8 16 68 0.16 0.75 0.68 6	2.8 3.7	4.2 4  5.5 4 

389 MA4.VP035-8/P18C MA4.VP035-8/P18C
