| zweischneidig | Kopierdrehen hinten, | Stechbreite b = 3.2 mm |
| mit Spanformer | ||
| miniature external machining, | indexable inserts, | depth of groove t max. = 11 mm |
| two-cutting edges | profiling at the back, | width of groove b = 3.2 mm |
with chipformer
| t max. X | b c R ��� ��� X | L L | R R | ||
| Rechts (R): wie gezeichnet Links (L): spiegelbildlich | righthand version (R): lefthand version (L): m | as shown irror image | |||
| Rechte Schneidpl. in rechte Linke Schneidpl. in linkem H Abmessunen in mm | m Halter alter | use RH insert in RH to LH insert in LH tool ho dimensions in mm | ol holder and lder | ||
| g Bestellnummer part number | b t max. | α | R β c | K10F CN45F AL41F P18C | Klemmhalter Typ toolholder type |
| R/L ZW41.32115515 R/L ZW41.32115535 | 3.2 11 3.2 11 | 55° 55° | 0.15 35° 4 0.35 35° 4 | | |
| R/L ZW41.32116108 | 3.2 11 | 61° | 0.08 29° 5 | | R/L HW10.∙∙∙ R/L HW15 |
| R/L ZW41.32116115 | 3.2 11 | 61° | 0.15 29° 5 | | .∙∙∙ R/L HW20.∙∙∙ |
| R/L ZW41.32116135 | 3.2 11 | 61° | 0.35 29° 5 | | |
| R/L ZW41.32116175 | 3.2 11 | 61° | 0.75 29° 5 | |
