Каталог Duemmel общий 2022 - страница 266
Навигация
Общий каталог Dümmel 2014
Каталог Dümmel дополнение 2017
Каталог Dümmel дополнение 2018
Общий каталог Dümmel 2015
| zweischneidig | Kopierdrehen vorne, | Stechbreite b = 3.2 mm |
| Schneide versetzt, mit Spanformer | ||
| miniature external machining, | indexable inserts, | depth of groove t max. = 11 mm |
| two-cutting edges | profiling in front, | width of groove b = 3.2 mm |
offset cutting edge, with chip former
c
E
X D
Schneid-Pfeil?
X kante??
L L R R
t max. R
| Rechts (R): wie gezeichnet | righthand version (R): as shown |
| Links (L): spiegelbildlich | lefthand version (L): mirror image |
| Rechte Schneidpl. in rechtem Halter | use RH insert in RH tool holder and |
| Linke Schneidpl. in linkem Halter | LH insert in LH tool holder |
| Abmessungen in mm | dimensions in mm |
| R/L ZW40.32116108 | 3.2 | 11 | 61° | 0.08 | 29° | 5 | | | |
| R/L ZW40.32116115 | 3.2 | 11 | 61° | 0.15 | 29° | 5 | | | R/L HW10.∙∙∙ |
| R/L HW15.∙∙∙ | |||||||||
| R/L ZW40.32116135 | 3.2 | 11 | 61° | 0.35 | 29° | 5 | | | R/L HW20.∙∙∙ |
| R/L ZW40.32116175 | 3.2 | 11 | 61° | 0.75 | 29° | 5 | | |
