Bohrungsbearbeitung	am Zapfen vorbei	D min. 12 / 16 mm
		Stechtiefe t max. 6 / 10 mm
		Nutbreite bis 3.0 / 4.0 mm
grooving, boring and profiling	type face grooving,	D min. 12 / 16 mm

in pivots depth of groove t max. 6 / 10 mm width of groove up to 3.0 / 4.0 mm

Rechts (R): wie gezeichn Links (L): spiegelbildlich s t max. d	et R	b R f D min. Klemmh toolhold	righthand (R): a lefthand versio alter Stirnseite er face	s shown n (L): mirror image D min.
Bestellnummer part number Abmessungen in mm	b+0.03	b (inch) f R s	d t max. dimensions in	D min. K10F AL41F P18C mm	Klemmhalter Typ toolholder type
R/L S014.1210.00	1.0	7.0 - 8.3	9 1.5	12  
R/L S014.1215.02 R/L S014.U219.02	1.5 1.98	7.5 0.2 8.3 0.078“ 8.0 0.2 8.3	9 2.5 9 3.0	12   12 
R/L S014.1220.02	2.0	8.0 0.2 8.3	9 3.0	12  
R/L S014.U223.02	2.39	0.094“ 8.4 0.2 8.3	9 3.0	12 
R/L S014.1225.02 R/L S014.1230.02	2.5 3.0	8.5 0.2 8.3 9.0 0.2 8.3	9 3.0 9 3.0	12  12 	614 614.A
R/L S014.U231.02	3.18	0.125“ 9.2 0.2 8.3	9 3.0	12 
R/L S014.1220.52	2.0	8.0 0.2 10.3	9 5.0	12  
R/L S014.U223.52	2.39	0.094“ 8.4 0.2 10.3	9 5.0	12 
R/L S014.1225.52	2.5	8.5 0.2 10.3	9 5.0	12 
R/L S014.1230.52	3.0	9.0 0.2 10.3	9 5.0	12  
R/- S014.1230.62	3.0	9.0 0.2 11.3	9 6.0	12 
R/L S018.1630.02 R/L S018.1640.02	3.0 4.0	11 0.2 15.8 12 0.2 15.8	11 10 11 10	16  16 	618 618.A
