Bohrungsbearbeitung	metrisches ISO-Gewinde,	D min. 9 / 11 mm
	Vollprofil, innen	Steigung P = 0.5 - 3.0
grooving, boring and profiling	type threading,	D min. 9 / 11 mm

metric ISO-thread, pitch P = 0.5 - 3.0 full profile, internal

Rechts (R): wie gezeichnet Links (L): spiegelbildlich f D min. b H1 60°		d E Kle too	s mmhal lholde	righthand (R): as lefthand version ter Stirnseite r face	shown (L): mirror image
Bestellnummer part number Steigung P pitch P Abmessungen in mm	H1 b	f	s	d E dimensions in m	D min. K10F AL41F P18C m	Klemmhalter Typ toolholder type
R/L S09.0205.02 0.50 R/L S09.0510.02 1.00 R/L S09.0815.02 1.50 R/L S09.0917.02 1.75 R/L S09.1020.02 2.00 R/L S09.1325.02 2.50 R/L S09.1630.02 3.00	0.27 0.06 0.54 0.12 0.81 0.18 0.95 0.20 1.08 0.25 1.35 0.31 1.62 0.37	5.5 5.5 5.5 5.5 5.5 5.5 5.5	3.65 3.65 3.60 3.60 3.55 3.55 3.55	6.2 3.25 6.2 3.00 6.2 2.80 6.2 2.70 6.2 2.60 6.2 2.50 6.2 2.20	9  9  9  9  9  9  9 	609
R/L S11.0510.02 1.00 R/L S11.0815.02 1.50 R/L S11.1020.02 2.00	0.54 0.12 0.81 0.18 1.08 0.25	6.7 6.7 6.7	4.30 4.30 4.30	8.0 3.60 8.0 3.30 8.0 2.90	11  11  11 	611
R/L S11.1325.02 2.50 R/L S11.1630.02 3.00	1.35 0.31 1.62 0.37	6.7 6.7	4.30 4.30	8.0 2.95 8.0 2.90	11  11 
