| D | m m | 3 | 5 | 10 | 15 | 20 | 30 | 40 | 50 | 60 | 80 | 100 |
| 12 | 0,379 | 0,490 | 0,693 | 0,849 | 0,980 | 1,200 | 1,386 | 1,549 | 1,697 | 1,960 | 2,191 | |
| 16 | f | 0,438 | 0,566 | 0,800 | 0,980 | 1,131 | 1,386 | 1,600 | 1,789 | 1,960 | 2,263 | 2,530 |
| 20 | e | 0,490 | 0,632 | 0,894 | 1,095 | 1,265 | 1,549 | 1,789 | 2,000 | 2,191 | 2,530 | 2,828 |
| re | m m | 3 | 5 | 10 | 15 | 20 | 30 | 40 | 50 | 60 | 80 | 100 |
| 1,3 | 0,177 | 0,228 | 0,322 | 0,395 | 0,456 | 0,559 | 0,645 | 0,721 | 0,790 | 0,912 | 1,020 | |
| 1,6 | f | 0,196 | 0,253 | 0,358 | 0,438 | 0,506 | 0,620 | 0,716 | 0,800 | 0,876 | 1,012 | 1,131 |
| 2,0 | e | 0,219 | 0,283 | 0,400 | 0,490 | 0,566 | 0,693 | 0,800 | 0,894 | 0,980 | 1,131 | 1,265 |
| 3,0 | 0,268 | 0,346 | 0,490 | 0,600 | 0,693 | 0,849 | 0,980 | 1,095 | 1,200 | 1,386 | 1,549 | |
| 4,0 | 0,310 | 0,400 | 0,566 | 0,693 | 0,800 | 0,980 | 1,131 | 1,265 | 1,386 | 1,600 | 1,789 |
| D | re | max | |
| LC 1210-KP | 1,0 | 4,8 | |
| LC 1210-KPF | 1,0 | 4,4 | |
| LC 1220-KP | 12 | 2,0 | 4,8 |
| LC 1210-RI | 1,0 | – | |
| LC 1220-RI | 2,0 | – | |
| LC 1230-RI | 3,0 | – | |
| LC 1610-KP | 1,0 | 6,6 | |
| LC 1613-KP | 16 | 1,3 | 6,6 |
| LC 1613-KPF | 1,3 | 5,9 | |
| LC 1630-KP | 3,0 | 6,6 | |
| LC 2010-KP | 1,0 | 8,5 | |
| LC 2016-KP | 20 | 1,6 | 8,5 |
| LC 2016-KPF | 1,6 | 7,5 | |
| LC 2040-KP | 4,0 | 8,5 |
| D | re | amax° | ap/l | |
| LC 1210-KP | 1,0 | 4,7 | 1,5/19 | |
| LC 1210-KPF | 1,0 | 3,8 | 1,5/23 | |
| LC 1220-KP | 12 | 2,0 | 4,4 | 2,0/26 |
| LC 1210-RI | 1,0 | – | – | |
| LC 1220-RI | 2,0 | – | – | |
| LC 1230-RI | 3,0 | – | – | |
| LC 1610-KP | 1,0 | 4,8 | 1,5/18 | |
| LC 1613-KP | 16 | 1,3 | 4,8 | 1,5/18 |
| LC 1613-KPF | 1,3 | 3,8 | 1,5/23 | |
| LC 1630-KP | 3,0 | 4,4 | 3,0/39 | |
| LC 2010-KP | 1,0 | 5,0 | 1,5/18 | |
| LC 2016-KP | 20 | 1,6 | 4,9 | 1,6/19 |
| LC 2016-KPF | 1,6 | 3,8 | 1,6/25 | |
| LC 2040-KP | 4,0 | 4,5 | 4,0/51 |
