| GI151 SNHQ 1102.. |
| GI152 SNHQ 1103.. |
| GI153 SNHQ 1203.. |
| GI154 SNHQ 1205.. |
| GI157 SNHQ 1204.. |
| GI158 SNHQ 1207 |
| Nm | |||||||
| DI011 | US 3504-T09P | 3,0 | M 3,5 | 4 | D-T07P/T09P | FG-15 | – |
| DI012 | US 70 | 5,0 | M 4 | 5 | D-T07/T15 | FG-15 | – |
| DI013 | US 71 | 5,0 | M 4 | 7 | D-T07/T15 | FG-15 | – |
| DI014 | US 72 | 5,0 | M 4 | 9 | D-T07/T15 | FG-15 | – |
| DI015 | US 73 | 5,0 | M 4 | 11 | D-T07/T15 | FG-15 | – |
| DI019 | US 3505-T09P | 3,0 | M 3,5 | 5 | D-T07P/T09P | FG-15 | HS 0830 |
| DI021 | US 3504-T09P | 3,0 | M 3,5 | 4 | D-T07P/T09P | FG-15 | HS 0830 |
| DI022 | US 70 | 5,0 | M 4 | 5 | D-T07/T15 | FG-15 | HS 0830 |
| DI023 | US 3505-T09P | 3,0 | M 3,5 | 5 | D-T07P/T09P | FG-15 | HS 1030 |
| DI024 | US 70 | 5,0 | M 4 | 5 | D-T07/T15 | FG-15 | HS 1030 |
| DI025 | US 70 | 5,0 | M 4 | 5 | D-T07/T15 | FG-15 | HS 1230 |
AC003 KS 2040 K.FMH40
| S | NHQ AZ | ||
| d | d1 l | s | |
| 1102 | 11,000 | 4,30 11,000 | 2,30 |
| 1103 | 11,000 | 4,30 11,000 | 2,70 |
| 1203 | 12,700 | 5,00 12,700 | 3,20 |
| 1204 | 12,700 | 5,00 12,700 | 4,50 |
| 1205 | 12,700 | 5,00 12,700 | 5,40 |
| 1207 | 12,700 | 5,00 12,700 | 7,00 |
l=d s
i
| ISO | ? PMKNSH | r | f | f | a | a | |
| e | min | max | p min | p max | |||
| SNHQ 1203AZEN | M8340 | + / - | – | 0,10 | 0,40 | – | – |
| 8215 | - | – | 0,10 | 0,40 | – | – | |
| 8240 | - | – | 0,10 | 0,40 | – | – | |
| SNHQ 1204AZEN | M8340 | + / - | – | 0,20 | 0,50 | – | – |
| 8215 | - | – | 0,20 | 0,50 | – | – | |
| 24° E | 8240 | - | – | 0,20 | 0,50 | – | – |
| SNHQ 1205AZEN | M8340 | + / - | – | 0,20 | 0,50 | – | – |
| 8215 | - | – | 0,20 | 0,50 | – | – | |
| 8240 | - | – | 0,20 | 0,50 | – | – | |
| SNHQ 1207AZEN | M8340 | + / - | – | 0,20 | 0,50 | – | – |
| 8215 | - | – | 0,20 | 0,50 | – | – | |
| 8240 | - | – | 0,20 | 0,50 | – | – | |
| SNHQ 1102AZTN | M8340 | + / - | – | 0,10 | 0,40 | – | – |
| 8230 | - | – | 0,10 | 0,40 | – | – | |
| 0,15 15° T | 8240 | - | – | 0,10 | 0,40 | – | – |
| SNHQ 1103AZTN | M8340 | + / - | – | 0,10 | 0,40 | – | – |
| 15° | 8230 | - | – | 0,10 | 0,40 | – | – |
| 8240 | - | – | 0,10 | 0,40 | – | – |
