Indexable Tools TypeStraight Shank φDc Stock φD1Main Blade Sub Blade Peripheral Blade φDc φD1 Tooling by DIJET Swing Ball SWBTyPE MT Shank Type / Weldon Shank Type / BT Shank Type Fig.8 ℓ MT. No. ℓ θn SWB-20070-MT3, SWB-20100-MT3, SWB-40090-MT5 R Md R ℓ1 ℓ2 ℓs ℓ2 L ■ BODY No. of inserts Dimensions (mm) Cat. No. Fig. R φDc ℓ ℓ2 ℓs L ℓ1 φD1 θn φDs Md SWB-20070-MT3 □ 1 1 2 30 70 86 156 40 18.7 4° MT3 M12×1.75 8 10 20 SWB-20100-MT3 □ 1 1 2 30 100 86 186 40 18.7 2° MT3 M12×1.75 8 SWB-25070-MT3 □ 1 1 2 35 70 86 156 – 23.5 – MT3 M12×1.75 8 12.5 25 SWB-25100-MT3 □ 1 1 2 35 100 86 186 – 23.5 – MT3 M12×1.75 8 SWB-32070-MT4-G □ 1 1 2 44 70 109 179 – 30.4 – MT4 M16×2 8 16 32 SWB-32100-MT4-G □ 1 1 2 44 100 109 209 – 30.4 – MT4 M16×2 8 SWB-40090-MT4 □ 1 1 2 50 90 109 199 – 36.9 – MT4 M16×2 8 20 40 SWB-40090-MT5 □ 1 1 2 50 90 136 226 66.8 36.9 8° MT5 M20×2.5 8 SWB-50100-MT5 □ 1 1 2 60 100 136 236 – 46.8 – MT5 M20×2.5 8 SWB-50120-MT5 □ 1 1 2 60 120 136 256 – 46.8 – MT5 M20×2.5 8 25 50 SWB-50150-MT5 □ 1 1 2 60 150 136 286 – 46.8 – MT5 M20×2.5 8 SWB-50170-MT5 □ 1 1 2 60 170 136 306 – 46.8 – MT5 M20×2.5 8 Note) 1) All cutters are supplied without inserts Modular Head Type Please refer Page B107 2) Please refer page C167-C171 for recommended cutting conditions and refer page C170 for machined form. 3) Please refer page C164 for selection of inserts. C162 : Standard stock items □ : Stock in Japan ○ : Soon to be deleted
