Tooling by DIJET Indexable Tools QM Mill PMETYPE MPM ⁄ PME ■ INSERTS TYPE High feed insert High hardened steel A A B B r r T T R2 type Grade (JC7560) Shoulder milling insert A High feed insert for unfavourable condition B A r T “MIRROR INSERT” for finishing side & bottom face B A r T B 1.2 Grade (JC7560) 1.9 T r PVD coated Dimensions (mm) Tole- Type Cat. No. rance JC5118 DH102 JC7560 JC8015 JC8050 A T B rε θ° High feed insert EOMT060210ZER M ● ● ● 6.5 2.5 4.3 1.0 13° EOMT060220ZER M ● ● 6.5 2.5 4.3 2.0 13° High feed insert for unfavourable EOMW060210ZER M ● ● ● 6.5 2.5 4.3 1.0 13° condition High hardened EOHW060210ZTR H ● 6.5 2.5 4.3 1.0 13° steel EOHW060220ZTR H ● 6.5 2.5 4.3 2.0 13° ZOMT060202ZER M ● ● 6.5 2.5 4.3 0.2 13° Shoulder milling ZOMT060204ZER M ● ● 6.5 2.5 4.3 0.4 13° insert ZOMT060208ZER M ● ● 6.5 2.5 4.3 0.8 13° YOHW060203ZER-12 H ● ● 6.5 2.6 4.3 0.3 13° ”Mirror Insert“ for finishing side YOHW060205ZER-12 H ● ● 6.5 2.6 4.3 0.5 13° & bottom face YOHW060208ZER-12 H ● ● 6.5 2.6 4.3 0.8 13° 10 inserts per case. Identification of grade for QM MILL insert Identification for the grades has been defined by different mark. JC5118 JC8050 / JC7560 IdentificationMark : Standard stock items □ : Stock in Japan ◎ : Soon to be stocked ○ : Soon to be deleted C093
