Tooling by DIJET Indexable Tools High Feed Diemaster SKSTYPE Through Coolant Hole Fig.3 Fig.4 φDs φDs φDc φDc ℓ2 ℓs ℓ2 ℓs L L ■ BODY / END MILL TYPE Dimensions (mm) No. Applicable Type Cat. No. Stock Fig. of flutes φDc ℓ2 ℓS L φDs Inserts Long SKS-2032-120-S32 ● 2 32 120 80 200 32 WD※※08... 3 type SKS-3032-120-S32 ● 3 32 120 80 200 32 WD※※06... 3 SKS-2020-130-S20 ● 2 20 130 120 250 20 1 WD※※05... SKS-2021-50E-S20 □ 2 21 50 200 250 20 1 Extra SKS-2025-180-S25 ● 2 25 180 120 300 25 3 Long SKS-2026-60E-S25 □ 2 26 60 240 300 25 WD※※06... 3 SKS-2032-180-S32 □ 2 32 180 120 300 32 WD※※08... 3 SKS-3032-180-S32 ● 3 32 180 120 300 32 WD※※06... 3 Note) 1. All cutters are supplied without inserts. Modular Head Type Please refer Page B012 2. Please refer page C027-C029, C033-C034 for recommended cutting conditions. 3. In case of using double clamping mechanism type, please refer page C009. : Standard stock items □ : Stock in Japan ○ : Soon to be deleted ■ PARTS Clamp screw Clamp set Wrench Applicable Inserts WO※※04... TSW-2556H – A-08SD WD※※05... DSW-306H – A-10 A-15T FaceMillType WD※※06... CSW-408H DCM-18 A-15 EndMillType A-20 WD※※08... DSW-4510H DCM-17 FaceMillType A-20SD EndMillType WD※※10... DSW-4512H DCM-17 A-20 Recommended Torque Clamp Screw (N·m) TSW-2556H 0.9 DSW-306H 1.8 CSW-408H 3.6 DSW-4510H 6.0 DSW-4512H 6.0 C037
