Tooling by DIJET QM MAX MQTTYPE MQT TyPE ■ Modular head MQT type Through coolant hole W C MD Fig.1 φDb φDc R0.3-R2.0 Lf W C MD Fig.2 φDb φDc θ° R0.3-R2.0 Lf Dimensions (mm) Parts Applicable Clamp No. Inserts Wrench Inclined Screw angleθ° Cat No. Stock of inserts φDc Lf φDb MD C W Fig. MQT-2016A00-M8 ● 2 16 23 14 M8 8 12 TSW-2556H YPHW1003＊＊Z＊R-＊＊ MQT-4020A00-M10 ● 4 20 30 18 M10 9 14 TSW-2556H 0° 1 ZPMT1003＊＊ZER-PL MQT-5025A00-M12 ● 5 25 35 22.5 M12 10 17 XP＊＊100308ZER-R DSW-2563H MQT-6035A00-M16 ● 6 35 43 29 M16 12 22 DSW-2563H A-08 MQT-2016A03-M8 ● 2 16 23 14 M8 8 12 TSW-2556H 3° ● 2 MQT-2020A03-M10 20 30 18 M10 9 14 TSW-2556H 2 MQT-2016A05-M8 ● 2 16 23 14 M8 8 12 TSW-2556H 5° ● MQT-2020A05-M10 2 20 30 18 M10 9 14 TSW-2556H Note) 1. All cutters are supplied without inserts. Clamp Screw Recommended Torque (N・m) 2. All cutters are supplied without wrench & MOLY. TSW-2556H 1.1 DSW-2563H 1.1 B085
