Общий каталог D'ANDREA 2018 - страница 209

Общий каталог D'andrea 2022

Общий каталог D'andrea 2022

FREZE TUTUCU

MAS 403 BT AD+B

PF

fig.1

208

fig.2

BT REF.	CODE	d1	d2	d3	M	L	L1	kg	fig.
MAS403 BT40-AD+B PF16.40	71MBT-B40PF1604					40		0.9
MAS403 BT40-AD+B PF16.110	71MBT-B40PF1611	16	32			110	17	1.3
MAS403 BT40-AD+B PF16.160	71MBT-B40PF1616					160		1.6
MAS403 BT40-AD+B PF22.40	71MBT-B40PF2204					40		1
MAS403 BT40-AD+B PF22.110	71MBT-B40PF2211	22	40			110	19	1.6
40 MAS403 BT40-AD+B PF22.160	71MBT-B40PF2216					160		2.1
MAS403 BT40-AD+B PF27.45	71MBT-B40PF2704					45		1.2
MAS403 BT40-AD+B PF27.110	71MBT-B40PF2711	27	50			110	21	2.2
MAS403 BT40-AD+B PF27.160	71MBT-B40PF2716					160		2.9
MAS403 BT40-AD+B PF32.50	71MBT-B40PF3205	32	60			50	24	1.7
MAS403 BT40-AD+B PF32.110	71MBT-B40PF3211					110		3
MAS403 BT40-AD+B PF40.55	71MBT-B40PF4005	40	70	�	�	55	27	2.1	1
MAS403 BT50-AD+B PF16.50	71MBT-B50PF1605					50		2.4
MAS403 BT50-AD+B PF16.110	71MBT-B50PF1611	16	32			110	17	2.8
MAS403 BT50-AD+B PF16.160	71MBT-B50PF1616					160		3.1
MAS403 BT50-AD+B PF22.50	71MBT-B50PF2205					50		2.6
MAS403 BT50-AD+B PF22.110	71MBT-B50PF2211	22	40			110	19	3.2
MAS403 BT50-AD+B PF22.160	71MBT-B50PF2216					160		3.7
50 MAS403 BT50-AD+B PF27.55	71MBT-B50PF2705					55		2.7
MAS403 BT50-AD+B PF27.110	71MBT-B50PF2711	27	50			110	21	3.6
MAS403 BT50-AD+B PF27.160	71MBT-B50PF2716					160		4.3
MAS403 BT50-AD+B PF32.55	71MBT-B50PF3205	32	60			55	24	3.2
MAS403 BT50-AD+B PF32.120	71MBT-B50PF3212					120		5.5
MAS403 BT50-AD+B PF40.60	71MBT-B50PF4006	40	88	667	M12	60	27	4.3
MAS403 BT50-AD+B PF40.120	71MBT-B50PF4012			.		120		7.1	2
MAS403 BT50-AD+B PF60.80	71MBT-B50PF6008	60	128.5	101.6	M16	80	40	6.8
