D 30° dA TiAlN SP Vollhartmetall-Spiralbohrer SP Solid carbide drills Foret hélicoïdal-carbure monobloc Ausführung 25 x D / Execution 25 x D / Version 25 x D Extra lange Ausführung, mit Innenkühlung / Extra long design, with through tool cool-ant/Version extra longue, avec refroidissement interne✓ 450 – 488 m7 HAK 140° h6 l4 l2 l 12,0 - 50,0 mm 30° FeinstkornUltra microgranulationGrain ultra finx2D5 PG 24 beschichtet coated revêtu Schaft Shank D dA l l2 l4 Tige m7 h6 SPC0030-0750-XL 3,0 6 125 85 75,0  SPC0035-0875-XL 3,5 6 139 99 87,5  SPC0040-1000-XL 4,0 6 153 113 100,0  SPC0045-1125-XL 4,5 6 167 127 112,5  SPC0050-1250-XL 5,0 6 181 141 125,0  SPC0055-1375-XL 5,5 6 195 155 137,5  SPC0060-1500-XL 6,0 6 209 169 150,0  SPC0070-1750-XL 7,0 8 237 197 175,0  SPC0080-2000-XL 8,0 8 265 225 200,0  SPC0085-2125-XL 8,5 10 283 239 212,5  SPC0090-2250-XL 9,0 10 297 253 225,0  SPC0100-2500-XL 10,0 10 326 282 250,0      Hauptanwendung Main application Application principale  Nebenanwendung Secondary application Application secondaire Alle Angaben in mm / Dimensions in mm VHM- / PM-HSS Werkzeuge | Solid carbide- / PM-HSS Tools | Outils carbure monobloc / PM-HSS 439
