Grooving and Cut-Off TN6010–––––––TN601036071363607154– TN60253607523360729636073253607378360746436072933607415TN6025360747736074933607328 TN7110–––––––TN7110––– THM–––––––THM––– TopGroove™ Grooving Inserts P ⅷ ⅷ ⅷ M ⅷ ⅷ ࠗ ⅷ first choice K ⅷ ࠗ ࠗ ࠗ ࠗ alternate choice N ⅷ ࠗ ⅷ S ⅷ ⅷ ⅷ Right-hand insert shown; left-handinsert is mirror image. H ࠗ ࠗ „NFD-K • Face Grooving Deep-Grooving Inserts insert cutting catalogue number size W Ap max RR T edges right hand NFD3M300RK 3 3,00 1,02 0,19 6,35 1 NFD3125RK 3 3,18 1,02 0,19 6,35 1 NFD4189RK 4 4,80 2,92 0,57 9,53 1 NFD4250RK 4 6,35 3,81 0,57 12,70 1 left hand NFD3M300LK 3 3,00 1,02 0,19 6,35 1 NFD3125LK 3 3,18 1,02 0,19 6,35 1 NFD4189LK 4 4,80 2,92 0,57 9,53 1 Right-hand insert shown; left-hand insert is mirror image. „NP-K • Profiling Inserts insert catalogue number size W RL T right hand NP2002RK 2 3,68 0,25 2,79 NP3002RK 3 4,83 0,25 5,08 NP3012RK 3 4,83 0,25 5,08 NOTE: Width tolerance is +/- 0,13mm. E66 widia.com
