TN6010360695736069293607174360712536069303606958–36070933606931360695936069323606960360713136069333606961 TN6025360739336074693607301360747536074703607397360749436075023607471360743936074723607440360747336074833607441 TN7110––––––––––––––– THM–––3607015–––3607031––––3607026–– Grooving and Cut-Off TopGroove™ Grooving Inserts P ⅷ ⅷ ⅷ M ⅷ ⅷ ࠗ ⅷ first choice K ⅷ ࠗ ࠗ ࠗ ࠗ alternate choice N ⅷ ࠗ ⅷ Right-hand insert shown; left-hand S ⅷ ⅷ ⅷ insert is mirror image. H ࠗ ࠗ „NR • Full Radius Inserts insert catalogue number size W RC T right hand NR2M050R 2 1,00 0,50 1,27 NR2M075R 2 1,50 0,75 2,79 NR2031R 2 1,58 0,79 2,79 NR3031R 3 1,58 0,79 2,39 NR2M100R 2 2,00 1,00 2,79 NR3M100R 3 2,00 1,00 2,39 NR2047R 2 2,39 1,19 2,79 NR3047R 3 2,39 1,19 3,81 NR2M125R 2 2,50 1,25 2,79 NR3M125R 3 2,50 1,25 3,81 NR2M150R 2 3,00 1,50 2,79 NR3M150R 3 3,00 1,50 3,81 NR3062R 3 3,18 1,59 3,81 NR2M175R 2 3,50 1,75 2,79 NR3M175R 3 3,50 1,75 3,81 (continued) widia.com E67
