METRIC Short Length Self Centering Drills • DIN 6539 27° 145° 2 OAL LCF LU 108M Plus DC DCON METRIC SERIES CONTINUED mm EDP NO, TOLERANCES (mm) CUTTING OVERALLDIAMETERLENGTHFLUTELENGTH CLEAREDLENGTH UNCOATED Ti-NAMITE-A(AlTiN)≤3 DIAMETER DC / DCON OAL LCF LU DC = +0,000/–0,010 2,9 46,0 16,0 12,0 62069 68677 DCON = h6 3,0 46,0 16,0 12,0 62071 68678 >3–6 DIAMETER 3,1 49,0 18,0 14,0 62073 68679 DC = +0,000/–0,012 3,2 49,0 18,0 14,0 62075 68680 DCON = h6 3,3 49,0 18,0 14,0 62077 68681 >6–10 DIAMETER 3,4 52,0 20,0 15,0 62079 68682 DC = +0,000/–0,015 3,5 52,0 20,0 15,0 62081 68683 DCON = h6 3,6 52,0 20,0 15,0 62083 68684 >10–16 DIAMETER DC = +0,000/–0,018 3,7 52,0 20,0 15,0 62085 68685 DCON = h6 3,8 55,0 22,0 17,0 62087 68686 3,9 55,0 22,0 17,0 62089 68687 4,0 55,0 22,0 17,0 62091 68688 STEELS 4,1 55,0 22,0 17,0 62093 68689 STAINLESS STEELS 4,2 55,0 22,0 17,0 62095 68690 CAST IRON 4,3 58,0 24,0 18,0 62097 68691 4,4 58,0 24,0 18,0 62099 68692 HIGH TEMP ALLOYS 4,5 58,0 24,0 18,0 62101 68693 TITANIUM 4,6 58,0 24,0 18,0 62103 68694 HARDENED STEELS 4,7 58,0 24,0 18,0 62105 68695 NON-FERROUS 4,8 62,0 26,0 20,0 62107 68696 4,9 62,0 26,0 20,0 62109 68697 PLASTICS/COMPOSITES 5,0 62,0 26,0 20,0 62111 68698 5,1 62,0 26,0 20,0 62113 68699 For patent 5,2 62,0 26,0 20,0 62115 68700 information visitwww.ksptpatents.com 5,3 62,0 26,0 20,0 62117 68701 5,4 66,0 28,0 21,0 62119 68702 5,5 66,0 28,0 21,0 62121 68703 5,6 66,0 28,0 21,0 62123 68704 5,7 66,0 28,0 21,0 62125 68705 5,8 66,0 28,0 21,0 62127 68706 5,9 66,0 28,0 21,0 62129 68707 6,0 66,0 28,0 21,0 62131 68708 continued on next page 294 DRILLS www.kDyRoIcLeLrSa-sgstool.com
