G2 - General purpose - Square CUTTING PARAMETERS INFO G2310-G2311 Material GroupISO 513 P1 P2 K1 P3 P4 P7 M1 K2 P5 M2 K3 N1 N2 N3 N4 Hardness/Rm ≤700 N/mm² 600÷1000 N/mm² ≤35 HRC ap x ae 0.5D x D 0.5D x D 0.5D x D 0.5D x D Vc (m/min) 60÷80 35÷55 25÷35 80÷100 CARBIDEDRILLS D fz fz fz fz(mm)(mm/z)(mm/z)(mm/z)(mm/z) SLOTTING 2 0.006 0.005 0.004 0.007 PU-HPU TA-4HTA 3 0.008 0.007 0.006 0.011 SUH 4 0.011 0.010 0.008 0.015 ALH 5 0.014 0.012 0.011 0.018 HRC 6 0.017 0.014 0.013 0.022 SUH MINI 8 0.023 0.019 0.017 0.029 HL 10 0.028 0.024 0.021 0.037 HSD 12 0.036 0.031 0.027 0.047 C-SD-TA < D3 mm: ap = 0.2D Material Group P1 P2 K1 P3 P4 P7 M1 K2 P5 M2 K3 N1 N2 N3 N4 ISO 513 Hardness/Rm ≤700 N/mm² 600÷1000 N/mm² ≤35 HRC ap x ae 1.5D x 0.3D 1.5D x 0.3D 1.5D x 0.3D 1.5D x 0.3D Vc (m/min) 70÷90 45÷65 30÷50 80÷120 D fz fz fz fz HSS (mm) (mm/z) (mm/z) (mm/z) (mm/z) DRILLS SIDE MILLING 2 0.007 0.006 0.005 0.009 3 0.011 0.009 0.008 0.014 LFTA 4 0.014 0.012 0.011 0.018 SUTAHSS-HSS/CO 5 0.018 0.015 0.013 0.023 6 0.021 0.018 0.016 0.027 8 0.028 0.024 0.021 0.037 10 0.035 0.030 0.026 0.046 12 0.045 0.038 0.034 0.059 < D3 mm: ae = 0.1D G2312 CARBIDE END-MILLS Material Group P1 P2 K1 P3 P4 P7 M1 K2 P5 M2 K3 N1 N2 N3 N4 G2 ISO 513 MDTA Hardness/Rm ≤700 N/mm² 600÷1000 N/mm² ≤35 HRC HF VH/UP MEF ap x ae 1.5D x 0.3D 1.5D x 0.3D 1.5D x 0.3D 1.5D x 0.3D ALU Vc (m/min) 55÷75 40÷60 20÷40 70÷90 MEX/MH UH/MH SIDE MILLING D(mm) fz(mm/z) fz(mm/z) fz(mm/z) fz(mm/z) 8 0.020 0.017 0.015 0.026 10 0.025 0.021 0.019 0.033 12 0.032 0.027 0.024 0.042 14 0.037 0.031 0.028 0.048 16 0.045 0.038 0.034 0.059 HSS END-MILLS CARBIDE BURRS 314
