G2 - General purpose - Square G2310-11-12 OSAWA <45NORMHRC INFO cylindrical shank, 3 flutes, long G2310 G2311-G2312 CARBIDEDRILLS PU-HPU TA-4HTA P M K N S H SUH ALH H I H I HRC H 1st choice I suitable SUH MINI HL HSD SLOTTING SIDE MILLING C-SD-TA D D Tol. C C Tol. d(h6) l l1 L z EDP No. Stock 2 0/-0.030 4 9 75 3 G2310020 h 3 0/-0.030 4 15 75 3 G2310030 h 4 0/-0.030 4 20 75 3 G2310040 h 5 0/-0.030 6 25 75 3 G2310050 h 6 0/-0.030 6 25 75 3 G2310060 h HSS DRILLS 4 0/-0.030 6 25 100 3 G2311040 h 5 0/-0.030 6 30 100 3 G2311050 h LFTA 6 0/-0.030 6 30 100 3 G2311060 h SUTAHSS-HSS/CO 7 0/-0.030 8 35 100 3 G2311070 h 8 0/-0.035 8 35 100 3 G2311080 h 9 0/-0.035 10 40 100 3 G2311090 h 10 0/-0.035 10 40 100 3 G2311100 h 11 0/-0.035 12 45 100 3 G2311110 h 12 0/-0.035 12 45 100 3 G2311120 h CARBIDE 8 0/-0.035 8 40 150 3 G2312080 h END-MILLS 10 0/-0.035 10 50 150 3 G2312100 h 12 0/-0.035 12 50 150 3 G2312120 h G2 MDTA 16 0/-0.040 16 70 150 3 G2312160 h HF VH/UP 20 0/-0.040 20 80 150 3 G2312200 h MEF ALU MEX/MH UH/MH HSS END-MILLS CARBIDE BURRS h stock standard f non-standard stock m stock exhaustion 313
