IC830 IC8250 IC20IC20IC20 IC8150 ISOTURN INSERTS 45º SC45MT-SM 90° 45º 45º Single-Sided Square Inserts for Finishing Applications IC=L D1 (CHAMELEON Multifunction Pocket System) RE S Dimensions Tough 1  Hard Recommended Machining Data ap f Designation L S RE D1 (mm) (mm/rev) SC45MT 100508-SM 9.53 5.00 0.80 4.50 • • • 0.50-3.00 0.10-0.30 • For user guide and cutting speed recommendations, see pages 122-134, 236-248 For tools, see pages: S-SUXCR/L-CM (110) • SUXCR/L-CM (54) Inserts for Machining Aluminum 80° 95° 95º L 95° WNGG-F3N Double-Sided Sharp-Edged Positive and Polished Rake Inserts RE for Finishing on Aluminum and IC S Other Non-Ferrous Materials Dimensions Recommended Machining Data ap f Designation L IC S RE (mm) (mm/rev) WNGG 060402-F3N-P 6.52 9.52 4.76 0.20 • 0.20-3.00 0.10-0.30 WNGG 060404-F3N-P 6.52 9.52 4.76 0.40 • 0.40-3.00 0.12-0.35 WNGG 060408-F3N-P 6.52 9.52 4.76 0.80 • 0.80-3.00 0.15-0.40 • For user guide and cutting speed recommendations, see pages 122-134, 236-248 For tools, see pages: A-PWLNR/L-X/G (104) • A/S-MWLNR/L-W (103) • DWLNR/L (10) • MWLNR/L-W (18) • PWLNR/L-X (11) • PWLNR/L-X-JHP (12) • PWLNR/L-X-JHP-MC (13) 80° 95º 95º 95º CNGG-F3N IC Double-Sided Sharp-Edged Positive and Polished Rake Inserts for Finishing on Aluminum and RE L S Other Non-Ferrous Materials Dimensions Recommended Machining Data ap f Designation L IC S RE (mm) (mm/rev) CNGG 090402-F3N-P 9.70 9.52 4.76 0.20 • 0.30-3.00 0.10-0.30 CNGG 090404-F3N-P 9.70 9.52 4.76 0.40 • 0.40-3.00 0.10-0.30 CNGG 090408-F3N-P 9.70 9.52 4.76 0.80 • 0.80-3.00 0.10-0.30 • For user guide and cutting speed recommendations, see pages 122-134, 236-248 For tools, see pages: A/S-PCLNR/L-X/G (102) • C#-PCLNR/L-X-JHP (24) • DCLNR/L (25) • PCLNR/L-X (22) • PCLNR/L-X-JHP (23) • PCLNR/L-X-JHP-MC (23) • AVC-PCLNR/L (96) A-A 95º CNGX-M3N IC A S 95º 95º Double-Sided Positive Rake Inserts with High Helical and Sharp Edge for Medium Machining on Non-Ferrous Materials RE A L Dimensions Recommended Machining Data ap f Designation L IC S RE (mm) (mm/rev) CNGX 090604-M3N-P 9.70 9.52 4.40 0.40 • 0.40-3.00 0.10-0.30 CNGX 090608-M3N-P 9.70 9.52 4.40 0.80 • 0.80-3.00 0.10-0.30 • PCLNR/L...X and A..-PCLNR/L-X are most recommended as they were designed especially for this insert • For user guide and cutting speed recommendations, see pages 122-134, 236-248 For tools, see pages: A/S-PCLNR/L-X/G (102) • C#-PCLNR/L-X-JHP (24) • DCLNR/L (25) • PCLNR/L-X (22) • PCLNR/L-X-JHP (23) • PCLNR/L-X-JHP-MC (23) 209
