IC908IC908IC908 ENDMILLS • SOLID CARBIDE • MULTI-MASTER 90° MM EDF DRVS THSZMS Interchangeable 3 Flute Solid Carbide Heads for Upper DC 90° DCONMS and Bottom Chamfering L7 L6 LF Dimensions Designation DC DCONMS NOF(1) L6 L7 LF THSZMS MM EDF074-090-58-3T04 7.40 5.80 3 0.90 1.00 10.00 T04 • MM EDF094-090-76-3T05 9.40 7.60 3 0.90 1.00 12.50 T05 • MM EDF116-090-95-3T06 11.60 9.60 3 1.00 1.00 16.50 T06 • • For shanks, see pages 84-91 • For clamping keys (should be ordered separately), tightening torques and clamping instructions, see pages 91-92 • Do not apply lubricant to the threaded connection. • For user guide see pages 44, 177-184 (1) Number of flutes lRE THSZMS MM TS-45 Interchangeable Solid KAPR Carbide Small Diameter DC DCONMS 45° Chamfering Heads CDX LF LU Dimensions Designation DC KAPR(1) CDX(2) RE NOF(3) l THSZMS DCONMS LU LF MM TS077-45-20A-4T05 7.70 45.0 1.20 0.20 4 15.20 T05 8.00 10.3 13.85 • • For clamping keys (should be ordered separately), tightening torques and clamping instructions, see pages 91-92 • Do not apply lubricant to the threaded connection (1) Tool cutting edge angle (2) Cutting depth maximum (3) Number of flutes CDX RE/FW DC MM GRIT-45AInterchangeable Solid KAPR KAPR Carbide Small Diameter 45° Chamfering Heads THSZMS CW Dimensions Designation DC KAPR(1) CDX(2) RE FW CW THSZMS NOF(3) MM GRIT18K-45A-3T6 17.70 45.0 1.40 0.10 - 3.47 T06 3 T-25/3* • MM GRIT18P-45A-3T6 17.70 45.0 1.40 0.10 - 3.47 T06 3 T-25/3* • MM GRIT22K-45A-4T8 21.70 45.0 1.70 - 1.50 5.55 T08 4 T-30/3 L* • MM GRIT28K-45A-6T10 27.70 45.0 4.00 - 0.50 9.80 T10 6 T-40/3 L* • • P-TYPE - Positive geometry for soft and gummy materials. • K-Type - For general steel machining. • Modification options on request. • Do not apply lubricant to the threaded connection. • For clamping instructions, see pages 91-92 • For shanks, see pages 84-91 (1) Tool cutting edge angle (2) Cutting depth maximum (3) Number of flutes * Optional, should be ordered separately 47
