BT MAS-403 LSCWS A 0.003 A 58-60 HRc ADJRGA BT-MAXIN SS BD_2 DCONNWS Power Chucks with BT MAS- DCONXWS 403 ADB Tapered Shanks DCONXWS BD CRKS THID LB LPR Designation SS DCONNWS(1) DCONXWS(2) BD BD_2 LPR LB ADJRGA LSCWS THID CRKS CDI(3) kg BT40 MAXIN 20X 85 40 6.0 20.0 51.00 52.00 85.00 58.0 12.00 68.0 M16 M16 0 1.12 BT40 MAXIN 32X108 40 6.0 32.0 69.00 70.00 108.00 81.0 13.00 83.0 M16 M16 0 1.60 BT50 MAXIN 20X105 50 6.0 20.0 51.00 52.00 105.00 67.0 13.00 69.0 M16 M24 0 3.90 BT50 MAXIN 20X105 ADB 50 6.0 20.0 51.00 52.00 105.00 67.0 13.00 69.0 M16 M24 0 0.00 BT50 MAXIN 32X106 50 6.0 32.0 69.00 70.00 106.00 68.0 14.00 83.0 M20X2 M24 0 3.80 BT50 MAXIN 32X106 ADB 50 6.0 32.0 69.00 70.00 106.00 68.0 14.00 83.0 M20X2 M24 0 0.00 BT50 MAXIN 32X135 50 6.0 32.0 69.00 70.00 135.00 97.0 15.00 84.0 M20X2 M24 0 4.60 (1) Minimum diameter by using a reduction collet (2) Max. diameter without a collet (1) 1 - Hole for data chip, 0 - Without hole for data chip 712-713 716 697 716 556-557 Spare Parts Designation BT40 MAXIN 20X 85 WRENCH MAXIN 20 HOOK* EXTRACTOR SC COLLETS* BT40 MAXIN 32X108 WRENCH MAXIN 32 HOOK* EXTRACTOR SC COLLETS* BT50 MAXIN 20X105 WRENCH MAXIN 20 HOOK* EXTRACTOR SC COLLETS* BT50 MAXIN 20X105 ADB WRENCH MAXIN 20 HOOK* EXTRACTOR SC COLLETS* BT50 MAXIN 32X106 WRENCH MAXIN 32 HOOK* EXTRACTOR SC COLLETS* BT50 MAXIN 32X106 ADB WRENCH MAXIN 32 HOOK* EXTRACTOR SC COLLETS* BT50 MAXIN 32X135 WRENCH MAXIN 32 HOOK* EXTRACTOR SC COLLETS* * Optional, should be ordered separately ADJRGA LSCWS A 0.003 A AT3 Taper 58-60 HRc SS BT-FC-MAXIN Power Chucks with BT MAS-403 Face Contact AD Tapered Shanks BDDCONWS CRKS THID LB LPR Designation SS DCONNWS(1) DCONXWS(2) BD LPR LB ADJRGA LSCWS THID CRKS CDI(3) kg BT40 FC MAXIN20X85 40 6.0 20.0 53.00 85.00 58.0 12.80 68.3 M16 M16 0 1.67 BT40 FC MAXIN32X108 40 6.0 32.0 70.00 108.00 80.5 13.00 83.0 M16 M16 0 1.65 BT50 FC MAXIN20X105 50 6.0 20.0 53.00 105.00 67.0 13.10 68.6 M16 M24 0 3.80 BT50 FC MAXIN32X106 50 6.0 32.0 69.90 106.00 68.0 14.30 83.3 M20X2 M24 0 3.92 (1) By using a reduction collet (2) Without a collet (1) 1 - Hole for data chip, 0 - Without hole for data chip BT-FC Face Contact Taper Face Contact Standard Spindle Spindle Face Contact Standard Holder Holder 716 697 712-713 716 556-557 Spare Parts Designation BT40 FC MAXIN20X85 WRENCH MAXIN 20 HOOK* EXTRACTOR SC COLLETS* BT40 FC MAXIN32X108 WRENCH MAXIN 32 HOOK* EXTRACTOR SC COLLETS* BT50 FC MAXIN20X105 WRENCH MAXIN 20 HOOK* EXTRACTOR SC COLLETS* BT50 FC MAXIN32X106 WRENCH MAXIN 32 HOOK* EXTRACTOR SC COLLETS* * Optional, should be ordered separately 632 ISCAR
