Общий каталог Ingersoll 2013 - 2014 - страница 139

HCLNR/L* d f 95° l *compatable with Sandvik’s COROMANT CAPTO* (**) system. Dimension (mm) Insert ComponentsLeverScrewShimShim PinNozzleWrench Designation d f l C4-HCLNR/L 27050-0904 40 27 50 CNMG 33 LCL 09-NX LCS 3 LSC 32 LSP 3A NZ 83 L-W 2.5 HDJNR/L* 27° d Max f 93° l *compatable with Sandvik’s COROMANT CAPTO* (**) system. Dimension (mm) Insert ComponentsLeverScrewShimShim PinNozzleWrench Designation d f l C4-HDJNR/L 27055-1305 40 27 55 DNMG 3.53.5 LCL 11-NX LCS 4 LSD 3.52 LSP 4 NZ 83 L-W 3 HSSNR/L* d f fs 45° l ls *compatable with Sandvik’s COROMANT CAPTO* (**) system. Dimension (mm) Insert ComponentsLeverScrewShimShim PinNozzleWrench Designation d f fs l ls C4-HSSNR/L 27042-0904 40 27 20.6 44 50.3 SNMG 33 LCL 09-NX LCS 3 LSS 32A LSP 3A NZ 83 L-W 2.5 HTGNR/L* HTJNR/L* d f 91° *(93°) l *compatable with Sandvik’s COROMANT CAPTO* (**) system. Dimension (mm) Insert ComponentsLeverScrewShimShim PinNozzleWrench Designation d f l C4-HTGNR/L 27050-13041C4-HTJNR/L 27050-130440 27 50402750 TNMG 2.53 LCL 08-NX LCS 3-NX LST 2.51.8 LSP 3B NZ 83 L-W 2.5 1Marked : Entering angle of HTJNR/L is 93 degrees. 139 (**) The trademark COROMANT CAPTO® is owned by Sandvik Intellectual Property AB.
