SDJNR/L EXTERNAL TOOL HOLDER WITH SCREW CLAMPING AND FOR NEGATIVE 55° DN__ INSERTS f b 27° max 93° l h h Designation h b l f SDJNL10-3A 0.625 0.625 4.000 0.750 SDJNR10-3A 0.625 0.625 4.000 0.750 SDJNR12-3B 0.750 0.750 4.500 1.000 For inserts, see pages 909, 911, 912, 915, 916. HARDWARE Accepts Insert Series Seat Insert Screw Seat Screw Seat Screw Wrench Torx Driver SDJNL10-3A DN__33_ SSD32 SO35120I SO50090S L-W4 DS-T10T SDJNR10-3A DN__33_ SSD32 SO35120I SO50090S L-W4 DS-T10T SDJNR12-3B DN__33_ SSD32 SO35120I SO50090S L-W4 DS-T10T 1069
