milling Grade IN2505 IN2530 IN2510 IN2504Grade IN10KIN2505 09 INSERTS HF M ML AL MNHU09-M MNHU09_ML MNCU09_AL INSL INSL INSL LE LE LE W1 RE S BSW1 RE S BSW1 RE S UNHU09_HF IC LE RE S Part Number Application RECornerRadiusBS LE INSLWiperCutting EdgeInsertLengthEff. LengthLengthW1InsertWidthS Thickness NOI Number of IndexesIHInsertHand MNHU090408R-M Multi-Purpose 0.031 - 0.314 0.338 0.338 0.232 4 Right • • • • MNHU090416R-M Multi-Purpose 0.062 - 0.314 0.338 0.338 0.224 4 Right • • • MNHU090404R-ML SS/Hi-Temp/Ti - Face Wiper 0.015 0.047 0.314 0.338 0.338 0.248 4 Right • MNHU090408R-ML SS/Hi-Temp/Ti - Face Wiper 0.031 0.031 0.314 0.338 0.338 0.248 4 Right • • MNCU090404FR-AL Grd/Pol for Al - Face Wiper 0.015 0.047 0.314 0.338 0.338 0.248 4 Right • MNCU090408FR-AL Grd/Pol for Al - Face Wiper 0.031 0.031 0.314 0.338 0.338 0.244 4 Right • REEQ LE INSLPart NumberApplicationProgram RadiusCutting EdgeInsertEquivalentEff. LengthLengthW1InsertWidthSThicknessNOINumber ofIndexesIHInsertHand UNHU090432R-HF Hi-Feed 0.125 0.059 0.338 0.338 0.187 4 Right • 09 HARDWARE **OPTIONAL** **OPTIONAL** **OPTIONAL** **OPTIONAL** **OPTIONAL** Screw Driver Handle Torx Driver Blade Retention Bolt Coolant Retention Bolt Wrench Torque Driver Handle Preset Torque Bit Torque Driver Bit 1TJ1F-1001780R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1 1TJ1F-1201781R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1 1TJ1F-1502281R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1 1TJ1F-10057S1R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1 1TJ1F-12077S9R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1 1TJ1F-15073S5R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1 1TJ1F-10015X7R01 SM35-088-10 DS-A00T DS-T106B - - 617MM DS-A00-.25-T DT-30-.25 DS-T10B1 1TJ1F-12017X8R01 SM35-088-10 DS-A00T DS-T106B - - 622MM DS-A00-.25-T DT-30-.25 DS-T10B1 1TJ1F-15017X9R01 SM35-088-10 DS-A00T DS-T106B - - 630MM DS-A00-.25-T DT-30-.25 DS-T10B1 TJ6F-15R01 SM35-088-10 DS-A00T DS-T106B SD-04-86 - - DS-A00-.25-T DT-30-.25 DS-T10B1 TJ6F-20R01 SM35-088-10 DS-A00T DS-T106B SD-06-46 SD-06-89 - DS-A00-.25-T DT-30-.25 DS-T10B1 TJ6F-25R01 SM35-088-10 DS-A00T DS-T106B SD-06-46 SD-06-89 - DS-A00-.25-T DT-30-.25 DS-T10B1 TJ6F-30R01 SM35-088-10 DS-A00T DS-T106B SD-08-46 SD-08-92 - DS-A00-.25-T DT-30-.25 DS-T10B1 TJ6F-40R01 SM35-088-10 DS-A00T DS-T106B SD-12-82 SD-12-99 - DS-A00-.25-T DT-30-.25 DS-T10B1 41
